PIN RECEPTACLES
for .022” - .032” diameter pins
M
ON
S
I
CHI
A
PINS
NE
D
0326
Basic
Part
Number
0326-1
0326-2
0326-3
0326-4
Board
Thick-
ness
.031
.062
.094
.125
Length
V
.062
.094
.125
.156
Depth
D
.040
.062
.062
.062
5295
0396
0326-X-19-XX-06-XX-10-0
Swage mount in .060 hole
5295-0-19-XX-06-XX-10-0
Solder mount in .086 min.
mounting hole
0396-0-15-XX-06-XX-10-0
Press-fit in .090 mounting hole
0298
Basic
Part
Number
Board
Thick-
ness
Length
V
9293
0298-1
0298-2
0298-3
0298-4
.031
.062
.094
.125
.051
.082
.113
.145
8864
0298-X-15-XX-06-XX-10-0
Swage mount in .060 hole
9293-0-15-XX-06-XX-10-0
Hex press-fit in .067 plated
thru hole
8864-0-15-XX-06-XX-10-0
Press-fit in.067 mounting hole
0664
Basic
Part
Number
Board
Thick-
ness
Length
V
0664-1
0664-2
0664-3
.094
.125
.188
.125
.156
.219
0664-X-15-XX-06-XX-10-0
Swage mount in .096 hole
SPECIFICATIONS
SHELL MATERIAL:
Brass Alloy 360, 1/2 Hard
CONTACT MATERIAL:
Beryllium Copper Alloy 172, HT
DIMENSION IN INCHES
TOLERANCES ON:
LENGTHS:
±.005
DIAMETERS: ±.002
ANGLES:
± 2°
ORDER CODE: XXXX - X - 1X - XX - 06 - XX - 10 - 0
BASIC PART #
SPECIFY SHELL FINISH:
01
200μ” TIN/LEAD OVER NICKEL
80
200μ” TIN OVER NICKEL
15
10μ” GOLD OVER NICKEL
RoHS
SPECIFY CONTACT FINISH:
01
200μ” TIN/LEAD OVER NICKEL
80
200μ” TIN OVER NICKEL
27
30μ” GOLD OVER NICKEL
2002/95/EC
CONTACT
#06
CONTACT (DATA ON PAGE 220)
w w w. m i l l - m a x . c o m
145
516-922-6000
