AA10U-024L-120SL: Description1-OUTPUT 10 W DC-DC REG PWR SUPPLY MODULE; CategoryPower/power management The power supply circuit; File Size323KB，2 Pages; ManufacturerEmerson Embedded Power; Environmental Compliance

Download Datasheet Parametric View All

AA10U-024L-120SL Overview

1-OUTPUT 10 W DC-DC REG PWR SUPPLY MODULE

AA10U-024L-120SL Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
package instruction	,
Reach Compliance Code	unknow
ECCN code	EAR99
Analog Integrated Circuits - Other Types	DC-DC REGULATED POWER SUPPLY MODULE
Efficiency (main output)	85%
Maximum input voltage	36 V
Minimum input voltage	9 V
Nominal input voltage	24 V
JESD-30 code	R-XDMA-P5
Maximum grid adjustment rate	0.5%
Maximum load regulation	0.5%
Number of functions	1
Output times	1
Number of terminals	5
Maximum operating temperature	75 °C
Minimum operating temperature	-40 °C
Maximum output voltage	12.12 V
Minimum output voltage	11.88 V
Nominal output voltage	12 V
Package body material	UNSPECIFIED
Package shape	RECTANGULAR
Package form	MICROELECTRONIC ASSEMBLY
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
Protect	CURRENT
Certification status	Not Qualified
surface mount	NO
technology	HYBRID
Temperature level	OTHER
Terminal form	PIN/PEG
Terminal location	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED
Maximum total power output	10 W
Fine-tuning/adjustable output	NO
Base Number Matches	1

Preview

Download Datasheet

View All

Astec Conventional Power

10 Watts

AA10U

Total Power:

Input Voltages:

No. of Outputs:

10 Watts

12V, 24V or 48V

Single, Dual

Electrical Specs

Input

Input range

Input capacitance

No load input power

Input reflected

ripple (P-P)

Efficiency

9 to 36 VDC; 18 to 75 VDC

48 models

1.5uF typical

24 models

2.7uF typical

150mW typical

48 Models

24 Models

82% (typ)

4mA

10mA

(see Note 2)

Output

Voltage tolerance

Special Features

•

Unencapsulated

Wide 4:1 input range

1 year warranty

1.0" x 2.0" x 0.38" case

Meets EN55022A for conducted noise

Line regulation

Load regulation

Noise/ripple

Short circuit protection

Overvoltage protection

Transient response

Switching frequency

Temperature coefficient

±1.0% (main); ±2.0% (aux)

(factory set-point)

+0.5% max (main); ±0.5% (aux)

±0.5% (10% load to full load

(singles))

±1.0% (10% load to full load (duals))

1% p-p (See Note 1)

Continuous Power Cycle

Zener clamp

1mS 50% Step load change to

within 1% Vout

All models 380kHz except

150S & 150D Models 300kHz (typ.)

±0.02%/°C max.

Environmental

Operating ambient temperature range:

-40°C to +75°C (no derating)

Baseplate: 105°C Max.

Storage Temperature: -55°C to +125°C

Humidity: 5% to 95% (non-condensing)

EMI/RFI Shielding: Five-Sided

MTBF: 361,000 hours (MIL-HDBK-217)

Isolation

I/O isolation

Insulation resistance

Insulation capacitance

Fuse

1500 VDC min

50 M ohm

220pF

.024 - 2.25A/250V

048 - 1A/250V

Safety

UL

TUV

UL 1950 Recognized

CAN22.2-950 Recognized

EN60950 Certified

64

America’s (USA): 1-888-41-ASTEC

Europe (UK): 44 (1384) 842-211

Asia (HK): 852-2437-9662
