General Purpose
Force Guided Relays
Force Guided Relay SR6 D/M
n
n
SCHRACK
4 pole relay with force guided contacts according to EN 50205
High insulation distances between electrical circuits
Typical applications
Emergency shut-off, press control, machine control, elevator and escalator
control, safety relays.
F0206-ED
ZT
Approvals
VDE Cert. No. 128935, UL E214025, TUV 968/EL 350
Technical data of approved types on request.
Coil Data
(continued)
Coil versions, DC-coil
Coil
Rated
Operate
code
voltage
voltage
VDC
VDC
024
24
18
036
36
27
040
40
30
048
48
36
060
60
45
110
110
83
1)
3 form A + 1 form B contacts
3 NO + 1 NC,
2 form A + 2 form B contacts
2 NO + 2 NC
Rated voltage
250VAC
Max. switching voltage
400VAC
Rated current
8A
Contact material
AgSnO
2
Contact style
single contact, force guided
type A according to EN 50205
Min. recommended contact load
5V, 10mA
Initial contact resistance
≤100mΩ at 1A, 24VDC
≤20Ω at 10mA, 5VDC
Frequency of operation, with/without load
6/150min
-1
Contact ratings, IEC60947-5-1,
on 1 form A (NO) contact
AC15-5A
DC13-6A
Mechanical endurance
10x10
6
operations
Contact Data
Contact arrangement
Release
voltage
VDC
2.4
3.6
4.0
4.8
6
11
Coil
resistance
Ω±10%
1)
480
1080
1333
1920
3000
1)
10080
1)
Rated coil
power
mW
1200
1200
1200
1200
1200
1200
Coil resistance ±12%.
All figures are given for coil without pre-energization, at ambient temperature +23°C.
Insulation Data
Coil data
Coil voltage range
Coil versions, DC-coil
Coil
Rated
Operate
code
voltage
voltage
VDC
VDC
005
5
3.8
006
6
4.5
009
9
6.8
012
12
9
018
18
13.5
021
21
16
01-2015, Rev. 0115
www.te.com
© 2015 Tyco Electronics Corporation,
a TE Connectivity Ltd. company.
5 to 110VDC
Release
voltage
VDC
0.5
0.6
0.9
1.2
1.8
2.1
Coil
resistance
Ω±10%
1)
21
30
68
120
270
368
Rated coil
power
mW
1190
1200
1191
1200
1200
1198
Initial dielectric strength
between open contacts
between contact and coil
between adjacent contacts
in longitudinal direction
Clearance/creepage
between open contacts
between contact and coil
between adjacent contacts
in longitudinal direction
Insulation to EN 50178, type of insulation
between contact and coil
between adjacent contacts
1500V
rms
4000V
rms
3000V
rms
4000V
rms
microdisconnection
≥5.5/5.5mm
≥5.5/5.5mm
≥15/15mm
reinforced
reinforced
Catalog and product specification according
to IEC 61810-1 and to be used only together
with the ‘Definitions’ section.
Catalog and product data is subject to the
terms of the disclaimer and all chapters of
the ‘Definitions’ section, available at
http://relays.te.com/definitions
Catalog product data, ‘Definitions’ section,
application notes and all specifications are
subject to change.
1
General Purpose
Force Guided Relays
Force Guided Relay SR6 D/M
(Continued)
Other Data
PCB layout / terminal assignment
Bottom view on solder pins
SCHRACK
Material compliance: EU RoHS/ELV, China RoHS, REACH, Halogen content
refer to the Product Compliance Support Center at
www.te.com/customersupport/rohssupportcenter
Ambient temperature
-25 to 70°C
Category of environmental Protection
IEC 61 810
RTIII
Weight
30g
Resistance to soldering heat THT
IEC 60068-2-20
260°C/5s
Packaging/unit
tube/10 pcs.
For more detailed information see product specification 2158003
2 form A + 2 form B, 2 NO + 2 NC contacts
S0368-CI
S0368-CJ
3 form A + 1 form B, 3 NO + 1 NC contacts
Dimensions
S0368-CK
S0367-DB
S0368-CL
Product code structure
Type
SR6
Relay with force guided contacts SR6 D/M
Contact arrangement
D
2 form A + 2 form B contacts (2 NO + 2 NC)
M
3 form A + 1 form B contacts (3 NO + 1 NC)
Contact material
4
AgSnO
2
Coil
Coil code: please refer to coil versions table (e.g. 024=24VDC)
Other types on request.
Typical product code
SR6
D
4
012
Product code
SR6D4012
SR6D4018
SR6D4021
SR6D4024
SR6D4040
SR6D4110
SR6M4006
SR6M4012
SR6M4018
SR6M4021
SR6M4024
SR6M4110
4 pole
relay with
force guided contacts
Type
Contact arrangement
2 form A + 2 form B,
2 NO + 2 NC
contacts
Contact material
AgSnO
2
3 form A + 1 form B,
3 NO + 1 NC
contacts
12VDC
18VDC
21VDC
24VDC
40VDC
110VDC
6VDC
12VDC
18VDC
21VDC
24VDC
110VDC
Coil
Part Number
1415078-1
7-1415354-1
8-1415353-1
6-1415027-1
9-1415366-1
1415062-1
6-1415053-1
7-1415353-1
1415354-1
6-1415353-1
3-1415353-1
1-1415354-1
2
01-2015, Rev. 0115
www.te.com
© 2015 Tyco Electronics Corporation,
a TE Connectivity Ltd. company.
Catalog and product specification according
to IEC 61810-1 and to be used only together
with the ‘Definitions’ section.
Catalog and product data is subject to the
terms of the disclaimer and all chapters of
the ‘Definitions’ section, available at
http://relays.te.com/definitions
Catalog product data, ‘Definitions’ section,
application notes and all specifications are
subject to change.
