General Purpose
Low Power PCB Relays
Miniature Power PCB Relay PBH 105°C
n
n
n
n
n
SCHRACK
1pole 6 A, 1 form C (CO) or 1 form A (NO) contact
Environmentally-friendly cadmium-free contacts
Class F coil system standard
For ambient temperatures up to 105°C
Product in accordance to IEC 60335-1
Typical applications
White goods, domestic appliances.
Z
Approvals
VDE Cert. No. 40008364, UL E214025
Technical data of approved types on request.
Coil Data
Coil voltage range
Operative voltage range, % of rated coil voltage
Coil versions, DC coil
Coil
Rated
Operate
code
voltage
voltage
VDC
VDC
005
5
3.75
006
6
4.50
009
9
6.75
012
12
9.00
018
18
13.50
022
22
16.50
024
24
18.00
048
48
36.00
Release
voltage
VDC
0.5
0.6
0.9
1.2
1.8
2.2
2.4
4.8
5 to 36 VDC
90 to 100 %
Coil
resistance
Ω±10%
70
100
225
400
900
1344
1600
6400
Rated coil
power
mW
357
360
360
360
360
360
360
360
Contact arrangement
1 form C (CO) or 1 form A (NO)
Rated voltage
250VAC
Max. switching voltage
400VAC
Rated current
6A
Limiting continuous current
6.5 A
Limiting making current, max 4 s, duty factor 10% 10A
Breaking capacity max.
1500VA
Contact material
AgNi 90/10
Frequency of operation, with/without load
360/36000h
-1
Operate/release time max.
10/20ms
Bounce time max., form A/form B
10/15ms
Contact ratings
Type
Contact
IEC 61810
PBH14
C (CO)
PBH34
A (NO)
PBH14
A of C
PBH34
A (NO)
PBH14
A of C
PBH34
A (NO)
UL 508
PBHx4
A (NO)
Load
6.5A, 250VAC, cosφ=1, 105°C
6.5A, 250VAC, cosφ=1, 105°C
6.5A, 250VAC, cosφ=1, 105°C
2A, 250VAC, cosφ=0.55, 105°C
2A, 250VAC, cosφ=0.55, 105°C
6.5A, 440VAC, cosφ=1, 105°C
6A, 415VAC, cosφ=1, 105°C
2x10
6
operations
Cycles
10x10
3
100x10
3
100x10
3
250x10
3
250x10
3
50x10
3
50x10
3
Contact Data
All figures are given for coil without pre-energization, at ambient temperature +23°C.
Other coil voltages on request.
Mechanical endurance, DC coil
Insulation Data
Initial dielectric strength
between open contacts
between contact and coil
Clearance/creepage
between contact and coil
form C (CO) version
form A (NO)
Material group of insulation parts
Tracking index of relay base
1000V
rms
2500V
rms
≥3/4mm
≥4/5mm
IIIa
PTI250
10-2014, Rev. 1014
www.te.com
© 2014 Tyco Electronics Corporation,
a TE Connectivity Ltd. company.
Catalog and product specification according
to IEC 61810-1 and to be used only together
with the ‘Definitions’ section.
Catalog and product data is subject to the
terms of the disclaimer and all chapters of
the ‘Definitions’ section, available at
http://relays.te.com/definitions
Catalog product data, ‘Definitions’ section,
application notes and all specifications are
subject to change.
1
General Purpose
Low Power PCB Relays
Miniature Power PCB Relay PBH 105°C
(Continued)
Other Data
SCHRACK
Material compliance: EU RoHS/ELV, China RoHS, REACH, Halogen content
refer to the Product Compliance Support Center at
www.te.com/customersupport/rohssupportcenter
Resistance to heat and fire
according EN60335, par.30
Ambient temperature, DC coil
-20 to +105°C
Category of environmental protection
IEC 61810
RTII - flux proof
Vibration resistance (functional)
form A/form B, 30 to 400Hz
>10/4g
Shock resistance (destructive)
>100g
Terminal type
PCB-THT
Weight
5.4g
Resistance to soldering heat THT
IEC 60068-2-20
270°C/10s
Packaging/unit
tube/35 pcs., box/1050 pcs.
PCB layout
1)
/ terminal assignment
Bottom view on solder pins
Dimensions
Layout note:
No openings (e.g. holes, slots, cutouts, unused pins, open through
connexions, etc.) allowed under the relay base. The relay base must be fully
covered by the PCB, recommended minimum distance between the relay
and the edge of the printed circuit board is 5 mm.
For more information, please contact our application support.
1)
Product code structure
Type
PB
Miniature Power PCB Relay PB 105°C
Version
H
High temperature version
Contact configuration
1
1 form C contact (1 CO)
3
Contact material
4
AgNi 90/10
Coil
Coil code: please refer to coil versions table
Other types on request.
Typical product code
PB
H
1
4
012
1 form A contact (1 NO)
Product code
PBH14005
PBH14006
PBH14009
PBH14012
PBH14018
PBH14022
PBH14024
PBH14036
PBH34005
PBH34006
PBH34009
PBH34012
PBH34018
PBH34022
PBH34024
PBH34036
High
temperature
version
Version
1 form C
1 CO contact
Contacts
Contact material
AgNi 90/10
1 form A
1 NO contact
5VDC
6VDC
9VDC
12VDC
18VDC
22VDC
24VDC
36VDC
5VDC
6VDC
9VDC
12VDC
18VDC
22VDC
24VDC
36VDC
Coil
Part number
9-1415356-1
8-1415356-1
7-1415356-1
6-1415356-1
6-1415357-1
7-1415357-1
6-1415355-1
9-1415355-1
5-1415356-1
4-1415356-1
3-1415356-1
2-1415356-1
8-1415357-1
9-1415357-1
1-1415356-1
1415356-1
2
10-2014, Rev. 1014
www.te.com
© 2014 Tyco Electronics Corporation,
a TE Connectivity Ltd. company.
Catalog and product specification according
to IEC 61810-1 and to be used only together
with the ‘Definitions’ section.
Catalog and product data is subject to the
terms of the disclaimer and all chapters of
the ‘Definitions’ section, available at
http://relays.te.com/definitions
Catalog product data, ‘Definitions’ section,
application notes and all specifications are
subject to change.
