SMT POWER INDUCTORS
Unshielded Drum Core - PA0390 Series
Height:
5.1mm Max
Footprint:
8.89mm x 6.10mm Max
Current Rating:
up to 6.0A
Inductance Range:
0.6µH to 113µH
Electrical Specifications @ 25°C — Operating Temperature -40°C to +130°C
Part
6,7
Number
PA0390.471
PA0390.102
PA0390.152
PA0390.222
PA0390.332
PA0390.472
PA0390.682
PA0390.103
PA0390.153
PA0390.223
PA0390.333
PA0390.473
PA0390.683
PA0390.104
Inductance
@ I
PK
A
DC
(µH ± 20%)
0.6
1.2
1.6
2.6
3.8
5.2
6.9
11
16
23
36
48
73
113
Irated
5
(A)
6
4.4
4.2
3.1
2.9
2.2
1.7
1.5
1.2
1
0.82
0.72
0.58
0.47
DCR (MAX)
(mΩ)
9.7
17.7
20
36.3
42.8
54.4
89.7
110.7
174.7
254.1
367
474
732
1109
Saturation Current
(A) @
25°C
7.7
5.3
4.5
3.5
3
2.6
2.2
1.9
1.5
1.2
0.99
0.87
0.67
0.53
Heating Current
(A)
6
4.4
4.2
3.1
2.9
2.2
1.7
1.5
1.2
1
0.82
0.72
0.58
0.47
NOTES:
1. The temperature of the component (ambient plus temperature rise)
must be within the specified operating temperature range.
2. Inductance tested at 100kHz, 250mV
RMS
3. Inductance drop = 10% typical at the Saturation Current.
4.
ΔT
= 40°C rise typical at the Heating Current
5. The rated current is the lower of the saturation or heating current.
6. Optional Tape & Reel packaging can be ordered by adding a "T" suffix to the part number
(i.e. PA0390.102 becomes PA0390.102T). Pulse complies to industry standard tape and reel
specification EIA481.
7. To order RoHS compliant part, add the suffix “NL” to the part number (i.e. PA0390.102
becomes PA0390.102NL and PA0390.102T becomes PA0390.102NLT).
Mechanical
SUGGESTED PAD LAYOUT
.240
6,10
MAX
.200
5,08
MAX
.065
1,65
.350
8,89
MAX
.160
4,06
Schematic
1
XXX
2
.200
5,08
.210
5,33
.250
6,35
.360
9,14
Weight
. . . . . . . . 0.2 grams
Tape & Reel
. . . . . 2500/reel
Dimensions:
Inches
mm
Unless otherwise specified, all tolerances are ± .010
0,25
.630
± .012
16,00
± 0,30
USER DIRECTION
OF FEED
TAPE & REEL
LAYOUT
.472
12,00
USA 858 674 8100
•
Germany 49 7032 7806 0
•
Singapore 65 6287 8998
•
Shanghai
86 21 54643211 / 2
•
China 86 755 33966678
•
Taiwan 886 3 4641811
www.pulseeng.com
12
SPM2007 (7/07)
