General Purpose Relays
Product Sets
Relay Package SNR
Relay package consisting of DIN-rail socket and relay
n
1 CO with 6 A rated load
n
Module width only 6.2 mm
n
Reduced system width for increased packing density
on the DIN rail
n
SCHRACK
Approvals
Relay: VDE Cert. No. 40010063, cULus E214025, cCSAus 2148326
F0260-BS
Socket: VDE Cert. No. 40010063, cULus E224918
Technical data of approved types on request
Contact configuration
1 CO
Contact set
single contact
Type of interruption
micro disconnection
Rated voltage/max. switching voltage AC
240/400 VAC
Rated current
6A
Maximum breaking capacity AC
1500 VA
Limiting breaking capacity,
max. 4 s, duty factor 10%
10 A
Contact material
AgSnO
2
AgSnO
2
gold plated
Minimum contact load
100mA, 12V
50mW
Rated frequency of operation
with/without load
6 / 1200 min
-1
Operate-/release time
max 12 / 5 ms
Bounce time NO/NC contact
max 3 / 8 ms
Contact ratings
For contact ratings see datasheet
Slim Interface Relay SNR
Contact data
Z
b
Input data
Rated input voltage DC
Operative range to IEC 61810
12, 24 VDC, 115, 230 VAC/VDC*
)
2
*) Version 115, 230 VAC/VDC equipped with 60 VDC relay
Insulation
Coil versions, DC coil
Coil
Rated
Operate
code
voltage
voltage
VDC
VDC
LB2
12
8.4
LC4
24
16.8
Coil versions, AC coil 50 Hz
Coil
Rated
Operate
code
voltage
voltage
50 Hz
VAC
VAC
SM5
115
82.0
TP0
230
160.0
Other coil voltages on request.
Release
voltage
VDC
0.6
1.2
Release
voltage
50 Hz
VAC
9.0
15.0
Coil
resistance
Ω±10%
848
3390
Coil
resistance
Rated coil
power
mW
184
220
Rated coil
power
50 Hz
Ω
mVA
not applicable
403
not applicable
736
Dielectric strength
coil-contact circuit
open contact circuit
Clearance / creepage coil-contact circuit
Material group of insulation parts
Insulation to IEC 60664-1
Type of insulation coil-contact circuit
open contact circuit
Rated insulation voltage
Pollution degree
Rated voltage system
Overvoltage category
4000 V
rms
1000 V
rms
≥ 6 / 8 mm
IIIa
reinforced
micro disconnection
250 V
3
2
240 V
230 / 400 V
III
10-2014, Rev. 1014
www.te.com
© 2014 Tyco Electronics Corporation,
a TE Connectivity Ltd. company
Datasheets and product specification
according to IEC 61810-1 and to be used
only together with the ‘Definitions’ section.
Datasheets and product data is subject to the
terms of the disclaimer and all chapters of
the ‘Definitions’ section, available at
http://relays.te.com/definitions
Datasheets, product data, ‘Definitions’ sec-
tion, application notes and all specifications
are subject to change.
1
General Purpose Relays
Product Sets
Relay Package SNR
(Continued)
Other data
SCHRACK
Mechanical endurance
10x10
6
cycles
Material compliance: EU RoHS/ELV, China RoHS, REACH, Halogen content
refer to the Product Compliance Support Center at
www.te.com/customersupport/rohssupportcenter
Environment
Ambient termperature range
-40...+55°C
Processing
Terminals
screw / cage clamp
Terminal screw torque acc. IEC 61984
0.5 Nm
max.
0.6 Nm
Wire cross section
single wire
0.14...2.5 mm
2
fine wire
0.14...2.5 mm
2
with bootlace crimp (DIN 46228/1)
0.14...2.5 mm
2
Insertion cycles
A (10)
Max. Insertion Force total
100 N
Mounting distance
≥ 0 mm, dense packing of sockets
Weight
32 g
Packaging unit
10 pcs
S0487-BA
Accessories
For accessories see datasheet
Accessories Slim Interface Relay SNR
S0487-AA
Version with
screw terminals
Version with
cage clamp terminals
Product code structure
Type
ST
Relay Package SNR
Version
3P
Relay set, SNR 1-pole CO (1 form C), 6 A, screw terminals
4P
Relay set, SNR 1-pole CO (1 form C), 6 A, cage clamp terminals
Contact material
2
AgSnO
2
, gold plated
Coil
LB2
12 VDC
SM5
115 VDC/VAC
3
AgSnO
2
24 VDC
230 VDC/VAC
Typical product code
ST
4P
3
TP0
LC4
TP0
ST3P2LC4
ST3P3LB2
ST3P3LC4
ST3P3SM5
ST3P3TP0
ST4P2LC4
ST4P3LB2
ST4P3LC4
ST4P3SM5
ST4P3TP0
Product code
ST3FLC4
ST3FSM5
ST3FTP0
ST4FLC4
ST4FSM5
ST4FTP0
Socket
Terminals
screw
V23092-S1024-A201
V23092-S1012-A301
V23092-S1024-A301
V23092-S1060-A301
V23092-S1024-A201
V23092-S1012-A301
V23092-S1024-A301
V23092-S1060-A301
Relay
AgSnO
2
gold pl.
AgSnO
2
Contacts
cage clamp
AgSnO
2
gold pl.
AgSnO
2
24VDC
12VDC
24VDC
115VDC/VAC
230VDC/VAC
24VDC
12VDC
24VDC
115VDC/VAC
230VDC/VAC
Coil
Part Number
3-1416100-0
3-1416100-1
3-1416100-2
3-1416100-3
3-1416100-4
3-1416100-5
3-1416100-6
3-1416100-7
3-1416100-8
3-1416100-9
Other types on request
2
10-2014, Rev. 1014
www.te.com
© 2014 Tyco Electronics Corporation,
a TE Connectivity Ltd. company
Datasheets and product specification
according to IEC 61810-1 and to be used
only together with the ‘Definitions’ section.
Datasheets and product data is subject to the
terms of the disclaimer and all chapters of
the ‘Definitions’ section, available at
http://relays.te.com/definitions
Datasheets, product data, ‘Definitions’ sec-
tion, application notes and all specifications
are subject to change.
