FEATURES AND SPECIFICATIONS
Reliable terminations for high-temperature applications.
Extreme thermal environments for electrical and electronic
circuitry demand Molex TEMP-TERMS. Their consistent, high
quality and rugged reliability assure your product’s proper
performance even at temperatures up to 1200° F (649° C).
TEMP-TERMS are designed and value-engineered for three dif-
ferent high ambient temperature ranges: 650°F, 900° F and
1200° F (343° C, 483° C and 649° C, respectively). The ter-
minals and splices in each range are fabricated from different
materials to obtain maximum thermal performance at opti-
mum initial and installed costs.
Temp-Terms
™
Ring Tongue Terminals
650° Temp-Terms (343°C)
VERSAKRIMP™
Operating conditions in this
maximum temperature
range calls for Molex
650° TEMP-TERMS terminals
and splices. Both terminals
and splices are constructed
of nickelplated copper and
are avai-able in the
VERSAKRIMP barrel style.
900° Temp-Terms (483°C)
Molex also offers a line of termi-
nals designed to perform satisfactorily
in ambient operating temperature
ranges up to 900° F (483° C). These
nickel-plated, steel alloy products are
available in the butted seam,
KRIMPTITE
®
barrel style. Ring tongue
terminals cover the 22 through 10 AWG
wire ranges to provide reliable perfor-
mance time after time even in these
hostile temperature environments.
1200° Temp-Terms (649°C)
The ultimate in thermal reli-
ability is afforded by the
Molex 1200° TEMP-
TERMS. The ring tongue ter-
minals, which are fabricated
from pure nickel, cover the
22 through 10 AWG wire
range. These terminals have
the butted seam KRIMPTITE
®
barrel.
Temp-Terms
™
Ring Tongue Terminals
W
L
C
LISTED
S
L
LISTED
L
UL
®
UL
®
Basic Dimensions
Wire Range
22-18
0.3-1.0mm
2
Stud
Size
5-6 (3-3.5)
8 (4)
10 (-)
1/4 (6)
5-6 (3-3.5)
5-6 (3-3.5)
8 (4)
10 (-)
1/4 (6)
5-6 (3-3.5)
8 (4)
10 (-)
1/4 (6)
5/16 (8)
3/8 (9)
Max. Width
W
.264 (6.7)
.264 (6.7)
.283 (7.2)
.477 (12.1)
.260 (6.6)
.322 (8.2)
.322 (8.2)
.322 (8.2)
.447 (12.1)
.385 (9.8)
.385 (9.8)
.385 (9.8)
.540 (13.7)
.540 (13.7)
.598 (15.2)
Min. Clearance
C
.240 (6.1)
.240 (6.1)
.240 (6.1)
.386 (9.8)
.209 (5.3
.275 (7.0)
.275 (7.0)
.275 (7.0)
.388 (9.9)
.303 (7.7)
.303 (7.7)
.303 (7.7)
.393 (10.0)
.393 (10.0)
.566 (14.4)
650° (343° C)
Versakrimp™
(Nickel Plated Copper)
Max. Length
Loose Piece
Mylar Tape
Order No.
Order No.
L
16-14
1.2-2.0mm
2
19203-0063
19203-0148
19203-0156
19203-0099
19203-0182
19203-0158
19203-0064
19203-0058
19203-0098
19203-0100
19203-0101
19203-0103
.640 (16.3)
.837 (21.2)
.785 (19.9)
.785 (19.9)
.952 (24.2)
1.056 (26.8)
12-10
3.0-6.0mm
2
900° (483° C)
Krimptite®
(Nickel Plated Steel)
Mylar Tape
Max. Length
Loose Piece
Order No.
Order No.
L
19203-0145
19203-0011
.660 (16.8)
19203-0146
19203-0014
.660 (16.8)
19203-0015
19203-0016
.670 (17.0)
19203-0144
19203-0005
.914 (23.2)
19203-0042
19203-0043
.639 (16.2)
19203-0047
19203-0048
.725 (18.4)
19203-0049
19203-0050
.725 (18.4)
19203-0051
19203-0052
.725 (18.4)
19203-0044
19203-0045
.916 (23.3)
19203-0091
19203-0092
.785 (19.9)
19203-0151
.785 (19.9)
19203-0093
19203-0094
.785 (19.9)
19203-0152
19203-0095
.952 (24.2)
19203-0153
19203-0096
.952 (24.2)
1200° (649° C)
Krimptite®
(Pure Nickel)
Mylar Tape
Max. Length
Loose Piece
Order No.
Order No.
L
19203-0034
19203-0077
19203-0083
19203-0085
19203-0035
19203-0078
19203-0084
19203-0086
.591 (15.0)
.560 (14.2)
.640 (16.3)
.640 (16.3)
19203-0113
19203-0114
.785 (19.9)
IMPORTANT: The 650° TEMP-TERMS cataloged above represent only the more
popular terminals and splices in the 22 through 10 AWG wire ranges. Other
650° TEMP-TERMS are available. Contact your Molex Customer Service
Representative for more information.
Molex Industrial Division
Tampa Bay Operations
Pinellas Park, FL
Phone
(800) 800-0449
Fax
(727) 528-1010
