62
Note for wire range
A
Type 105
Screw type terminal block, solderable, centerline
3.5 mm / 0.138 inches, wire entry 45°, wire protector
Type 305
Screw type terminal block, solderable, centerline
3.5 mm / 0.138 inches, wire entry 55°, lift system
Additional wire sizes and/or
combinations of same size
wires as follows:
Type 105
### 2 No. 22 - 20 AWG
(field-wiring);
2 No. 30 - 20 AWG or
1 No. 30 - 18 AWG
(factory-wiring)
Technical Data
V / A / AWG
V / A / AWG
0.33 - 1 mm²
300 / 10 / 22 - 18
300 / 10 / 22 - 18
130 V / 2.5 kV / 10 A
Technical Data
V / A / AWG
300 / 6 / 28 - 16
0.08 - 1.0 mm² 160 V / 2.5 kV / 10 A
Insulation co-ordination according to EN 60664-1
Clearance and creepage distances min. 2.6 mm
Insulating material class
CTI 600
Overvoltage category
III
III
II
Pollution degree
3
2
2
Rated voltage
200
500
500
Rated test voltage
2.5
4
2.5
Protection category according
to IEC 529
IP20
Tightening torque UL
2.2 lb-in max.
Min. insul. strip length
5 mm
Solder pin dimension
0.5 x 0.9 mm
Recommended pc board hole
dia.
Ø 1.1 mm
Solder pin length
3.5 mm
Pole size
2 - 24
Color
black
Insulation co-ordination according to EN 60664-1
Clearance and creepage distances min. 2.1 mm
Insulating material class
CTI 600
Overvoltage category
III
III
II
Pollution degree
3
2
2
Rated voltage
160
400
400
Rated test voltage
2.5
4
2.5
Protection category according
to IEC 529
IP00
Tightening torque UL
1.3 lb-in max.
Min. insul. strip length
5 mm
Solder pin dimension
0.9 mm
Recommended pc board hole
dia.
Ø 1.2 mm
Solder pin length
3.7 mm
Pole size
2 - 16
Color
black
Dimensions in mm
1 mm = 0.0394 in.
Dimensions in mm
1 mm = 0.0394 in.
L = (pole size - 1) x centerline + 3.5 mm / 0.138 inches
L = (pole size - 1) x centerline + 3.5 mm / 0.138 inches
Part numbers (P/N)
Type 105
centerline 3.5 mm / 0.138 inches
(information: page 56)
Complete the part number by
adding the pole size.
Part numbers (P/N)
Type 305
(information: page 56)
Complete the part number by
adding the pole size.
02 03 04 05 06 07 08
09 10 11 12 13 14 15 16
centerline 3.5 mm / 0.138 inches
02 03 04 05 06 07 08
09 10 11 12 13 14 15 16
17 18 19 20 21 22 23 24
P/N
311051
P/N
313051
Standard pole sizes
Available on demand. Minimum order quantity 5000
pieces per item.
Standard pole sizes
Available on demand. Minimum order quantity 5000
pieces per item.
