5-175613-6: DescriptionCONNECTOR, 50 CONTACT(S), FEMALE, STRAIGHT TELECOM AND DATACOM CONNECTOR, SOLDER, RECEPTACLE; CategoryThe connector The connector; File Size103KB，1 Pages; ManufacturerTE Connectivity; Websitehttp://www.te.com

Download Datasheet Parametric View All

5-175613-6 Overview

CONNECTOR, 50 CONTACT(S), FEMALE, STRAIGHT TELECOM AND DATACOM CONNECTOR, SOLDER, RECEPTACLE

5-175613-6 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
Maker	TE Connectivity
Reach Compliance Code	unknown
Is Samacsys	N
Body/casing type	RECEPTACLE
Connector type	TELECOM AND DATACOM CONNECTOR
Contact to complete cooperation	GOLD (30) OVER NICKEL
Contact completed and terminated	GOLD (30) OVER NICKEL
Contact point gender	FEMALE
Contact material	PHOSPHOR BRONZE
DIN compliance	NO
empty shell	NO
Filter function	NO
IEC compliance	NO
JESD-609 code	e4
MIL compliance	NO
Manufacturer's serial number	175613
Mixed contacts	NO
Installation method	STRAIGHT
Installation type	BOARD
Options	GENERAL PURPOSE
Shell material	POLYAMIDE
Termination type	SOLDER
Total number of contacts	50
UL Flammability Code	94V-0
Base Number Matches	1

Preview

Download Datasheet

View All

C orporate Hom e

Electronic Components

Se gm e nts

W ho W e Are

My Account

Searc h

Products

Documentation

Resources

My Account

Customer Support

Home

Products

By Type

C HAMP C onnectors

Product Feature Selector

> Product Details

5-175613-6 Product Details

Live Product Chat

Product Photo

1.27 [.050] Series I, HD, FH and J Connectors

5 of 6 EU R oHS/ELV C om plia nt

(

Find R oHS C om plia nt

Alte rna te s

Sta te m e nt of C om plia nce

)

Quick Links

C heck Pricing & Availability

Search for Tooling

Product Feature Selector

C ontact Us About This Product

5-175613-6

T E I nternal N umber: 5 - 1 7 5 6 1 3 - 6

Product Highlights:

C onnector

Receptacle

Number of Positions = 50

1.27 mm C enterline

Standard Profile

View all Features

A dd to M y P art L is t

Reques t Sample

Find Similar P roduc ts

Obsolete

C ontact Product Information C enter

Buy P roduc t

Documentation & Additional Information

Product Drawings:

None Available

Catalog Pages/Data Sheets:

REPRESENTATIVE TERMINALS AND C ONNEC TORS

(PDF, English)

Product Specifications:

C HAMP .050(I) Board-to-Board C onnector

(PDF, English)

Application Specifications:

None Available

Instruction Sheets:

None Available

CAD Files:

None Available

List all Documents

Product Features

(Please use the Product Drawing for all design activity)

Product Type Features:

Product Type

= C onnector

Gender

= Receptacle

Number of Positions

= 50

Profile

= Standard

PC B Mount Style = Through Hole

PC B Retention Feature = No

PC B Mount Angle

= Vertical

C onnector Type

= High Density (HD)

PC B Mount Polarization

= Without

C olor = Black

Used For = Board To Board Applications

Sealed Bottom = Without

Termination Related Features:

Termination Post Length (mm [in])

= 3.10 [0.122]

Body Related Features:

C enterline (mm [in])

= 1.27 [0.050]

PC B Retention Method

= None

Contact Related Features:

C ontact Mating Area Plating Material

= Gold (30)

C ontact Base Material = Phosphor Bronze

Housing Related Features:

Housing Temperature Rating

= Standard

Housing Material = Nylon

Housing Flammability Rating = UL 94V-0

Industry Standards:

RoHS/ELV C ompliance

= ELV compliant, 5 of 6 C ompliant

Lead Free Solder Processes

= Wave solder capable to 240?C

Operation/Application:

Application

= Standard

Other:

Brand = AMP

Additional Information:

Product Line Information
