Connectivity....for
Business-Critical Continuity
SMA Hand-Formable
Fixed Length Cable
Assemblies for
RF/Microwave Applications
Emerson Network Power Connectivity Solutions
has added to its Johnson
®
product line a series of SMA Hand-Formable, fixed-length cable assemblies for
RF/Microwave applications.
These Hand-Formable cable assemblies are an excellent alternative to semi-rigid
cables which are more costly and less flexible during early stages of design and
effectively eliminate additional tooling charges.
In conjunction with our popular Johnson® brand of connectors on each end, these
SMA Hand-Formable cable assemblies are constructed of a silver-plated, copper
covered steel conductor, with an additional copper-tin composite braid foil. When
RF interference isn’t an option, these cables provide 100% shielded cable coverage
assuring an outstanding VSWR and low insertion loss of up to 18 GHz.
Available in a variety of lengths off-the-shelf, these Hand-Formable SMA cable
assemblies offer users a high quality, low cost solution. As with all other RF cable
assemblies provided by Johnson®, these assemblies are also available in custom
lengths upon request.
Key Features & Benefits
•Constructed with Johnson®
Premium SMA Connectors
• Assembled with 50 Ohm
Hand-Formable Microwave Cable
• 100% Shielded Cable Coverage
• Available in .086 & .141
cable diameters
• Off-the-Shelf Availability
• Low-cost alternative to
Custom-made cables
• Excellent VSWR to 18 GHz
for Microwave applications
Connectivity Solutions
SMA Hand-Formable Fixed Length Cable Assemblies
Connectivity....for
Business-Critical Continuity
Part No.
415-0081-003
415-0081-004
415-0081-005
415-0081-006
415-0081-007
415-0081-008
415-0081-012
415-0081-018
415-0081-024
415-0082-003
415-0082-004
415-0082-005
415-0082-006
415-0082-007
415-0082-008
415-0082-012
415-0082-018
415-0082-024
*Ref Plane to Ref Plane
Cable Assembly
Hand-Formable .086 Cable
Hand-Formable .086 Cable
Hand-Formable .086 Cable
Hand-Formable .086 Cable
Hand-Formable .086 Cable
Hand-Formable .086 Cable
Hand-Formable .086 Cable
Hand-Formable .086 Cable
Hand-Formable .086 Cable
Hand-Formable .141 Cable
Hand-Formable .141 Cable
Hand-Formable .141 Cable
Hand-Formable .141 Cable
Hand-Formable .141 Cable
Hand-Formable .141 Cable
Hand-Formable .141 Cable
Hand-Formable .141 Cable
Hand-Formable .141 Cable
Conn.1
SMA Plug, Straight
SMA Plug, Straight
SMA Plug, Straight
SMA Plug, Straight
SMA Plug, Straight
SMA Plug, Straight
SMA Plug, Straight
SMA Plug, Straight
SMA Plug, Straight
SMA Plug, Straight
SMA Plug, Straight
SMA Plug, Straight
SMA Plug, Straight
SMA Plug, Straight
SMA Plug, Straight
SMA Plug, Straight
SMA Plug, Straight
SMA Plug, Straight
Conn.2
SMA Plug, Straight
SMA Plug, Straight
SMA Plug, Straight
SMA Plug, Straight
SMA Plug, Straight
SMA Plug, Straight
SMA Plug, Straight
SMA Plug, Straight
SMA Plug, Straight
SMA Plug, Straight
SMA Plug, Straight
SMA Plug, Straight
SMA Plug, Straight
SMA Plug, Straight
SMA Plug, Straight
SMA Plug, Straight
SMA Plug, Straight
SMA Plug, Straight
Length*
3 in.
4 in.
5 in.
6 in.
7 in.
8 in.
12 in.
18 in.
24 in.
3 in.
4 in.
5 in.
6 in.
7 in.
8 in.
12 in.
18 in.
24 in.
Electrical Ratings
Part No.
415-0081-003
415-0081-004
415-0081-005
415-0081-006
415-0081-007
415-0081-008
415-0081-012
415-0081-018
415-0081-024
415-0082-003
415-0082-004
415-0082-005
415-0082-006
415-0082-007
415-0082-008
415-0082-012
415-0082-018
415-0082-024
Length
(inches)
3.00±.05
4.00±.05
5.00±.10
6.00±.10
7.00±.10
8.00±.10
12.00±.15
18.00±.15
24.00±.15
3.00±.05
4.00±.05
5.00±.10
6.00±.10
7.00±.10
8.00±.10
12.00±.15
18.00±.15
24.00±.15
Nominal
Electrical
Delay (ns)
0.36
0.49
0.61
0.73
0.85
0.97
1.46
2.19
2.92
0.36
0.49
0.61
0.73
0.85
0.97
1.46
2.19
2.92
Insertion Loss (dB Max)
Vs Frequency (GHz)
0 to 1
0.12
0.14
0.17
0.19
0.21
0.23
0.32
0.46
0.59
0.09
0.10
0.12
0.13
0.14
0.15
0.20
0.27
0.35
1 to 2
0.17
0.20
0.23
0.26
0.30
0.33
0.45
0.64
0.83
0.13
0.15
0.17
0.18
0.20
0.22
0.29
0.39
0.50
2 to 4
0.24
0.29
0.33
0.38
0.42
0.47
0.65
0.92
1.19
0.19
0.22
0.24
0.27
0.30
0.32
0.43
0.59
0.75
4 to 6
0.29
0.35
0.40
0.46
0.51
0.57
0.79
1.12
1.45
0.24
0.27
0.30
0.34
0.37
0.40
0.54
0.74
0.94
6 to 12
0.41
0.49
0.57
0.65
0.72
0.80
1.11
1.58
2.04
0.34
0.39
0.44
0.49
0.54
0.59
0.79
1.09
1.39
12 to 18
0.51
0.60
0.70
0.79
0.89
0.98
1.36
1.93
2.49
0.43
0.49
0.56
0.62
0.69
0.75
1.01
1.40
1.79
VSWR (MAX)
Vs Frequency (GHz)
0 to 1
1 to 2
2 to 18
1.06
1.10
1.1+.01f
1.06
1.10
1.1+.01f
Emerson Network Power.
The global leader in enabling
Business-Critical Continuity.
Emerson Network Power Connectivity Solutions
Johnson
299 Johnson Ave., Suite 100
Waseca, MN 56093
For product Information:
www.EmersonNetworkPower.com/Connectivity
or call 800.247.8256
