F-215
™
D I S CR ETE
(2,00 mm) .0787"
S2SD–10–24–L–05.00–DS
S2SD–30–24–L–05.00–S
S2SD, S2SDT SERIES
TIGER EYE CABLE ASSEMBLY
SPECIFICATIONS
For complete specifications
see www.samtec.com?S2SD
or www.samtec.com?S2SDT
Insulator Material:
Black LCP
Contact Material:
BeCu
Plating:
Au over 50µ" (1,27 µm) Ni
Wire:
24, 26, 28 or 30 AWG
Operating Temp Range:
-10°C to +105°C (PVC)
-40°C to +125°C (*Teflon
®
)
Current Rating
(S2SD-24/T2M):
3.8 A per pin
(1 pin powered per row)
Voltage Rating:
250 VAC
RoHS Compliant:
Yes
*DuPont
™
Teflon
®
is a
registered trademark of the
E.I. du Pont de Nemours
and Company or its affiliates.
™
Mates with:
T2M
Choice of
PVC or
Teflon
®
cable
™
24, 26, 28
or 30 Wire
gauge
Optional
Screw Down
• Tiger Eye™ contacts
• Retention latches
TYPE
ALSO AVAILABLE
(MOQ Required)
• Other sizes
Contact Samtec.
PINS PER
ROW
WIRE
GAUGE
PLATING
OPTION
ASSEMBLED
LENGTH
END
OPTION
END 2
OPTION
S2SD
= Double Row
PVC Cable
APPLICATION
–24C CABLE
COLOR CODING
PIN
1
2
3
4
5
6
7
8
9
10
ETC
S2SDT
= Double Row
*Teflon
®
Cable
(24, 28, 30
Gauge only)
–05,
–07,
–10,
–15,
–20,
–25,
–30
(Standard
sizes)
–24
–24C
= Color
Coded
Cable
(S2SD
only)
–L
= 10µ"
(0,25 µm)
Gold on
contact
–“XX.XX”
= Wire
Length
in Inches
(69,85 mm)
02.75" min.
–S
= Single End
(Only available
with –D,
–DR & –DS)
COLOR
BROWN
RED
ORANGE
YELLOW
GREEN
VIOLET
GRAY
WHITE
BLACK
BLUE
REPEAT
–26
–28
–30
(7,52)
.296
No. of positions x
(2,00) .0787 + (3,50) .138
02
= Notch up,
= Double End
straight
(Pin 1 to Pin N-1)
Specify "S" for
single ended
and "D" for
double ended. = Notch down,
straight
(Pin 1 to Pin 2)
= Retention
Latch
(-SR mates
= Notch up,
with T2M-WT)
crossed
(Pin 1 to Pin N)
–D
–NUS
–NDS
–(X)R
–NUX
(2,11) .083
(2,64)
.104
(5,15)
.203
(2,00)
.0787
01
–(X)S
(4,42)
.174
(11,38)
.448
= Screw Down
(10 positions
minimum)
(mates with
T2M-DS)
–NDX
= Notch down,
crossed
(Pin 1 to Pin 1)
Notes:
For wiring option information
refer to drawing on web.
Teflon cable is
intended for crimp only.
Contact Samtec for
solderable cable applications.
Some lengths, styles and
options are non-standard,
non-returnable.
®
Assembly
Length
± (3,18)
.125
(1,60)
.063
–SR
–D–NUS
WWW.SAMTEC.COM
Due to technical progress, all designs, specifications and components are subject to change without notice.
