data sheet
selector switch
type 01
main features
MINIatUre desIGN, COst eFFeCtIVe
Very robust designs for rugged environments
Gold plated contacts: 3 micron
High switching torques: Up to 20 Ncm
Operating temperature: Up to -40 to +85°C
Front panel sealing: Up to Ip68
Various options and customizations
››
››
››
››
››
››
type 01
standard product variety
■›
■›
■›
■›
■›
■›
■›
■›
■›
possible customizations
■›
■›
■›
■›
■›
soldering eyelets or pins for pCB
From 1 x 12 to 4 x 3 poles/positions per wafer
single or dual wafer
30, 36 or 60° indexing angle
shorting or non-shorting
2.0, 4.0 or 6.0 Ncm switching torque
Ip60 or Ip68 front panel sealing
Configurable end stops
shaft diameter: 3, 4 or 6 mm
shaft dimension and shape
Bushing dimensions
switching torque
Hollow shaft, inner shaft
Others
typical applications
■›
■›
■›
Industrial controls
avionics, instrumentation, test systems
Medical and audio equipment
nut (supplied)
11.2
2
11
Wrench size 10 mm
M8 x 0.75
Spare Part
Order number (10 pcs. bag)
- Brass nickel plated: 4024-81
1.0
www.elma.com
1/6
0.5
data sheet
selector switch
type 01
1
preference types selection chart
number of wafers
function
(poles x positons)
1 x 12, endless rotating
1 x 12, endless rotating
1 x 12
2 x 12
1 x 11
2 x 11
2x6
4x6
4x3
8x3
standard type key
With SOlder eyeletS
01-1123
01-2123
01-1183
01-2183
01-1113
01-2113
01-1263
01-2263
01-1433
01-2433
1
for other types/options, see type key.
indexing angle 30°, shorting
contact
arrangement
With PinS fOr PcB
01-1123-20
_
01-1183-20
_
01-1113-20
_
01-1263-20
_
01-1433-20
_
indexing angle 30°, non-shorting
contact
arrangement
number of wafers
function
(poles x positons)
1 x 12, endless rotating
1 x 12
1x1
standard type key
With SOlder eyeletS
01-1124
01-1184
01-1114
With PinS fOr PcB
01-1124-20
01-1184-20
01-1114-20
2x6
01-1264
01-1264-20
4x3
01-1434
01-1434-20
indexing angle 36°, non-shorting
contact
arrangement
number of wafers
function
(poles x positons)
1 x 10, endless rotating
1 x 10
indexing angle 60°, non-shorting
contact
arrangement
number of wafers
function
(poles x positons)
1 x 6. endless rotating
standard type key
With SOlder eyeletS
01-1104
With PinS fOr PcB
01-1104-20
standard type key
With SOlder eyeletS
01-1103
01-1193
With PinS fOr PcB
01-1103-20
01-1193-20
1x6
01-1164
01-1164-20
2x3
01-1234
01-1234-20
4x2
01-1424
01-1424-20
stop pins
packaging unit
10 pcs.
10 pcs.
order number
4007-36
4007-35
On switches with fixed end-stop, additional stops can be set, by means of a plastic pin, on any
position between 2 and the maximum (stop pins to be ordered separately).
www.elma.com
2/6
data sheet
selector switch
type 01
specifications
mechanical data
coding/output:
Switching torque (new condition):
rotational life:
fastening torque of nut:
12 positions max. (30° indexing); shorting or non-shorting
10 positions max. (36° indexing); shorting
6 positions max. (60° indexing); non-shorting
2.0, 4.0 or 6.0 ncm (+/- 25%), additional wafers may increase switching torque
25'000 cycles min.
300 ncm max.
electrical data
functions:
Switching mode:
load current:
Switching voltage:
contact resistance(new condition):
insulation resistance:
Switching capacity:
dielectric withstanding voltage:
from 1 x 12 to 4 x 3 poles/positions per wafer (max. 2 wafers)
Shorting (for 30° and 36° indexing)
non-shorting (for 30° and 60° indexing)
2 A max. (resistive load)
42 Vdc max.
10 m Ω max.
10
11
Ω min. (contact to contact /housing)
1 pf max. (contact to contact)
500 Vdc during 60 seconds (pin to pin, pin to housing)
material data
Shaft:
Bushing:
housing:
nut:
contact plating:
insulation material:
Soldering leads:
Stainless steel
nickel silver
fiber enforced plastic
Brass with glossy nickel plating
Gold; 3 µm
Wafer: hf ceramic, rotor: Polybutylene (PBtB)
Alloy copper, gold plated
environmental data
Operating/storage temperature range:
iP sealing:
Vibration:
flammability:
–40 to +85°c max.
iP60, optional iP68 (2 bar, 1 h) shaft/front panel sealing
10 G
rms
max. @ 10 to 2000 hz
Ul94-hB
packaging quantity
tray:
10 pcs.
soldering conditions
hand soldering:
Wave soldering:
340°c max. during 2 s max.
280°c max. peak temperature during 5 s max.
switching modes
for information about switching modes please see technical explanations at the end of the catalog
www.elma.com
3/6
data sheet
SW= Key spanner spanner
SW= Key
2
1
SW10
2
1
ø2
ø2
M8 x 0,75
SW10
M8 x 0,75
selector switches
type 01
ø4
Front panel cut out
7,5
7,5
drawings
wItH sOlder eyelets
M8 x 0,75
2
ø4
2,2
7,5
W= Key spanner
0,8
6
AL = 39,2 = 39,2
AL
0,8
6
18
18
ø18
ø18
ey spanner
M8 x 0,75
M8 x 0,75
ø4 7,5
ø2
ø4
18,2
ø4
7,5
18,2
ø4
8,2
0,8
6
AL = 0,8
39,2
18
6
18
ø18
ø18
0,8
6
AL = 39,2 = 39,2
AL
0,8
22,3
6
22,3
40,3
40,3
20,2
20,2
M8 x 0,75
M8 x 0,75
SW10 2 39,2 1
SW =
AL =
spanner
key
1
8,2
SW10 2
wItH pINs FOr pCB
18,2
0,8
6
AL = 0,8
39,2
6
22,3
22,3
40,3
11
10
18,2
ø4
drilling diagram for 30°
20,2
indexing angle
40,3
3,5
20,2
1x12
0°
3,5°
3
12 1
2
3
8,2
drilling diagram for 36°
indexing
Drilling diagram
view from the
shaft end
9
8
7
A
6
5
ø4
~14,5
AL = 39,2
Locating lug
36
°
10
1x10
3,5°
1
2
3
4
7,5
SW10
2
1
SW10
1
SW10 2
SW10 1 2
M8 x 0,75
ø2
Front panel cut out
front panel cut out
8,2
2,2
1
1x10, endless rotating
Locating lug
10
9
8
7
A
5
6
1°
5
1
2
3
4
A
9
7
5
6
ø1,3
8
ø1,5
7,5
4
16,7
45°
°
15
drilling diagram for 60°
indexing angle
1 x 11
1
11
10
9
8
7
A
6
2
3
4
5
6B
5B
4B
2x6
1A 2A 3A
A
B
3B 2B 1B
4A
5A
6A
4x3
1A 2A 3A
3D
2D
1D
A
D
B
C
1B
2B
3B
6
A
5
4
2
3
3B
2A
A
B
3A
30
1x6
3,5°
°
60
1
2x3
1A
4x2
°
°
33,5
1A
A
D
2C
2A
B
C
1C
1B
2B
2D
3C 2C 1C
60
°
1D
2B
1B
45°
special shaft diameter
Front-panel cut out
3 mm
2,2
7,5
6 mm
2,2
7,5
type 01 switches are also available with the folllowing shaft diameters:
Ø
3 mm
6 mm
al (standard)
59 mm
28 mm
bushing
M6 x 0.75 x 6.0 mm
M10 x 0.75 x 8.0 mm
nut size
10 mm
14 mm
6,2
10,2
hollow shaft system
2,2
hollow shaft
2,2
10,2
10,2
7,5
10,2
Hollow shaft to allow concentric operation of either two switches or, for
example, a switch and a potentiometer. the inner shaft (Ø 3 mm) must
be ordered separately.
inner shaft
7,5
Front panel cut out
Must be ordered separately for switches with hollow shaft.
switches with 2 drive shafts
Front panel cut out
10,2
It is possible for two switches to be operated individually by concentric
shafts on the same mounting. when ordering, the type number of each
switch should be given and specified.
10,2
www.elma.com
4/6
data sheet
selector switches
type 01
type key
01
–
_
_
_
_
–
_
_
_
_
_
_
_
_
standard type key
(see page 83)
shaft diameter
0
m
n
4 mm
3 mm
6 mm
number of wafers
(max. 2)
factory set end-stop
00
11
10
09
08
07
06
05
04
03
02
Standard
11 pos.
10 pos.
9 pos.
8 pos.
7 pos.
6 pos.
5 pos.
4 pos.
3 pos.
2 pos.
number of poles
number of poles per wafer
factory set character
defined by elma
(see page 83, is composed of switching
mode, poles and positions)
shaft length (al)
switching mode
3
4
Shorting
non-shorting
000
59 mm (Ø 3 mm shaft)
39.2 mm (Ø 4 mm shaft)
28 mm (Ø 6 mm shaft)
custom
(e.g. 18.5 mm = 185)
1
xxx
torque
-
m
n
4.0 ncm (standard)
2.0 ncm
6.0 ncm
customized shaft length
Shaft length (Al) description measured from
mounting face
(see picture below).
(4 mm shaft: max. Al = 80 mm, 6 mm shaft:
max. Al = 28 mm).
1
pin style, ip sealing
00
eyelets
20
Pins for PcB
2
30
eyelets, iP68
2
70
Pins for PcB, iP68
Only available for one wafer version with
3 or 4 mm shaft diameter.
2
www.elma.com
5/6
