Cartridge and Axial Lead Fuses
2AG > Fast Acting > 2206 Series
2206 Series,
Lead-Free 2AG, Fast-Acting Fuse
®
Description
The 2AG Fast-Acting Axial Leaded Fuses provide the same
performance characteristics as their 3AG counterpart, while
occupying one-third the space.
Features
with Underwriter’s
Laboratories Standard
UL 248-14
in most solvents with
thermoplastic sleeve
Ampere Range
form and with various
lead forming dimensions
Lead-free
Agency Approvals
Agency
®
Agency File Number
Applications
Used as supplimentary protection in appliance or utilization
equipment to provide individual protection for components
or internal circuits.
Electrical Characteristics for Series
% of Ampere
Rating
100%
135%
200%
Opening Time
E10480
750mA - 3A
750mA - 3A
750mA - 3A
Electrical Characteristic Specifications by Item
Ampere
Rating
(A)
.750
1
2
3
Max
Voltage
Rating
(V)
300
300
300
300
Nominal
Cold
Resistance
(Ohms)
0.1520
0.1027
0.0497
0.0317
Nominal
Melting
I
2
t (A
2
sec)
1.05
2.22
1.50
4.62
Nom
Voltage
Drop
(mV)
N/A
N/A
N/A
N/A
Nom
Power
Dissipation
(W)
N/A
N/A
N/A
N/A
Agency Approvals
Amp
Code
0.75
001
002
003
Interrupting
Rating
®
100A@300Vac
10KA@125Vac
x
x
x
x
x
x
x
x
©2009 Littelfuse, Inc.
Specifications are subject to change without notice.
Please refer to www.littelfuse.com for current information.
Revised: March 11, 2009
2206 Series
Cartridge and Axial Lead Fuses
2AG > Fast Acting > 2206 Series
Temperature Rerating Curve
Average Time Current Curves
.750A
1.00A
0.1
1
2.00A
100
10
TIME IN SECONDS
1
0.1
0.01
0.001
10
100
CURRENT IN AMPERES
1000
Soldering Parameters - Wave Soldering
300
Temperature
(°C) - Measured on bottom side of board
280
260
240
220
200
180
160
140
120
100
80
60
40
20
100
110
120
130
140
150
160
170
180
190
200
210
220
230
240
10
20
30
40
50
60
70
80
90
0
0
Recommended Process Parameters:
Wave Parameter
Preheat:
(Depends on Flux Activation Temperature)
3A
Lead-Free Recommendation
100
°
C
150
°
C
60-180 seconds
Solder Pot Temperature:
Solder Dwell Time:
260
°
2-5 seconds
Recommended Hand-Solder Parameters:
Time
(Seconds)
Preheat
Time
Dwell
Time
Cooling
Time
Note: These devices are not recommended for IR or
Convection Reflow process.
2206 Series
Revised: March 11, 2009
©2009 Littelfuse, Inc.
Specifications are subject to change without notice.
Please refer to www.littelfuse.com for current information.
Cartridge and Axial Lead Fuses
2AG > Fast Acting > 2206 Series
Product Characteristics
Materials
Terminal Strength
Solderability
Product Marking
Test Condition A
2003-01 Annex A
ratings
for 240 hours
Salt Spray
Vibration
Humidity
Operating
Temperature
Thermal Shock
Dimensions
Part Numbering System
2206
000P
Series
4.7 (.184")
.635
(.025")
14.48
(.57")
38.1
(1.50") TYP.
Packaging
Packaging Option
2206 Series
N/A
N/A
100
1000
N/A
N/A
Packaging Specification
Quantity
Quantity &
Packaging Code
Reel Size
©2009 Littelfuse, Inc.
Specifications are subject to change without notice.
Please refer to www.littelfuse.com for current information.
Revised: March 11, 2009
2206 Series
Cartridge and Axial Lead Fuses
©2009 Littelfuse, Inc.
Revised: March 11, 2009
Specifications are subject to change without notice.
Please refer to www.littelfuse.com for current information.
