STANDARD RF INDUCTORS - SURFACE MOUNT
SMRF2007
TRADITIONAL
Pb
SMRF2007LF
*
PART
NUMBER
SMRF2007-100M
SMRF2007-220M
SMRF2007-470M
SMRF2007-680M
SMRF2007-101M
SMRF2007-151M
SMRF2007-181M
SMRF2007-271M
SMRF2007-331M
SMRF2007-391M
SMRF2007-561M
SMRF2007-681M
SMRF2007-821M
SMRF2007-102M
SMRF2007-122M
SMRF2007-152M
SMRF2007-182M
SMRF2007-222M
SMRF2007-272M
SMRF2007-332M
SMRF2007-392M
SMRF2007-472M
COMPLIANT
RoHS
Wirewound,Toroidal, Vertical Mount
L
µH
0.10
0.22
0.47
0.68
1.0
1.5
1.8
2.7
3.3
3.9
5.6
6.8
8.2
10
12
15
18
22
27
33
39
47
TEST
FREQ
MHz
10
10
10
10
10
10
10
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
SRF
MIN
MHz
1292
624
321
214
180
125
114
86
82
78
64
58
51
51
45
45
34
25
25
25
24
20
DCR
OHMS
MAX
0.019
0.029
0.040
0.059
0.062
0.072
0.077
0.088
0.096
0.100
0.120
0.170
0.240
0.260
0.360
0.520
0.640
0.220
0.250
0.330
0.470
0.550
SATURATION
CURRENT
mA DC
4500
3000
2000
1600
1400
1200
1000
900
800
700
600
540
490
440
400
340
310
98
88
78
72
60
CURRENT
RATING
mA DC
3100
2510
2130
1760
1710
1590
1540
1440
1380
1350
1230
1040
871
873
711
592
533
909
853
743
622
575
All part numbers provide 20% tolerance on inductance
Custom designs are available to meet your specific requirements; please contact factory
*Add “LF” suffix for RoHS requirement. Example: SMRF2007-100MLF
Gowanda designates a component RoHS-compliant by adding “LF” (lead free) to the part number.
These LF components meet the ≤ .1% lead requirement and they are compatible with 260°C soldering processes.
350
300
250
200
150
Q VS. FREQUENCY
SMRF2007 SERIES
FRONT VIEW
0.310 ± 0.010
(7.87 ± 0.254)
MARKING:
Gowanda L
µH
SIDE VIEW
0.150 ± 0.010
(3.81 ± 0.254)
10 µH
0.290 ± 0.010
(7.37 ± 0.254)
Q
3.9 µH
0.400
(10.2)
MAX
BOTTOM VIEW
0.165 ± 0.010
(4.19 ± 0.254)
RECOMMENDED FOOT PRINT
0.200
(5.08)
47 µH
100
50
0
1.0 µH
NOTES:
• Operating Temperature Range:
-55°C to +125°C
• Current Rating is based on a 35°C temperature
rise at an ambient temperature of 90°C
• Saturation Current is the approximate value that
will reduce the initial inductance by 10%
TAPE AND REEL SPECS:
Pcs./Reel maximum:
Pitch between parts:
Tape width:
Reel diameter:
0.47 µH
0.10 µH
0.185
(4.70)
1
FREQUENCY MHz
10
100
0.100
(2.54)
in. (mm)
700
12 mm
24 mm
13 in.
One Magnetics Pkwy, Gowanda, NY 14070 • (t) 716-532-2234 • (f) 716-532-2702 • sales@gowanda.com
www.gowanda.com
030414
