Part Number:
Status:
Description:
0440681002
Active
4.20mm (.165") Pitch Mini-Fit BMI™ Surface Mount Compatible Header, Dual Row,
Vertical, 10 Circuits, 6.35mm (.250") PCB Thickness, with Snap-In Metal Pins, PA
Polyamide Nylon 4/6, UL 94V-0, with Tin (Sn) Over Nickel (Ni) Plating, with Solderable
Retenti
Documents:
3D Model
Drawing (PDF)
General
Product Family
Series
Application
Application
Comments
Product Specification PS-43810-001 (PDF)
RoHS Certificate of Compliance (PDF)
Series image - Reference only
PCB Headers
44068
Board-to-Board
Wire-to-Board
Current = 12A max. per circuit when header is
mated to a receptacle loaded with 45750 series
terminals crimped to 16 AWG wire.. See Molex product
specification PS-43810-001 for additional current de-
rating information.
Mini-Fit BMI™
No
10
10
10
Black
10
Yes
No
Yes
None
Yes
Brass
Tin
Tin
High Temperature Thermoplastic
2
Vertical
0.174 In
4.42 mm
Yes
Yes
0.094 In
2.39 mm
Tray
0.165 In
4.20 mm
0.165 In
4.20 mm
101.6
2.54
101.6
2.54
Yes
EU RoHS
China RoHS
ELV and RoHS
Compliant
REACH SVHC
Contains SVHC: No
Halogen-Free
Status
Not Reviewed
Need more information on product
environmental compliance?
Email productcompliance@molex.com
Please visit the Contact Us section for any
non-product compliance questions.
Duration at Max.
Process Temperature
(seconds)
Lead-free Process
Capability
Max. Cycles at Max.
Process Temperature
Process Temperature
max. C
5
Product Name
Physical
Breakaway
Circuits (Loaded)
Circuits (maximum)
Circuits Detail
Color - Resin
Durability (mating cycles max)
First Mate / Last Break
Glow-Wire Compliant
Guide to Mating Part
Keying to Mating Part
Lock to Mating Part
Material - Metal
Material - Plating Mating
Material - Plating Termination
Material - Resin
Number of Rows
Orientation
PC Tail Length (in)
PC Tail Length (mm)
PCB Locator
PCB Retention
PCB Thickness Recommended (in)
PCB Thickness Recommended (mm)
Packaging Type
Pitch - Mating Interface (in)
Pitch - Mating Interface (mm)
Pitch - Term. Interface (in)
Pitch - Term. Interface (mm)
Plating min: Mating (µin)
Plating min: Mating (µm)
Plating min: Termination (µin)
Plating min: Termination (µm)
Polarized to Mating Part
SMC & Wave Capable
(TH only)
1
235
Search Parts in this Series
44068 Series
Mates With
42385 , 42474 , 44475 , 44516 , 5557d
Polarized to PCB
Shrouded
Stackable
Surface Mount Compatible (SMC)
Temperature Range - Operating
Termination Interface: Style
Electrical
Current - Maximum
Voltage - Maximum
Material Info
Reference - Drawing Numbers
Product Specification
Sales Drawing
Yes
Fully
No
No
-40°C to +105°C
Through Hole
7A
600V AC (RMS)/DC
PS-43810-001
SD-44068-051
