0603CS-330EGTS datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Passive components> inductor> 0603CS-330EGTS

0603CS-330EGTS: DescriptionGeneral Purpose Inductor, 0.033uH, 2%, 1 Element, Ceramic-Core, SMD, CHIP, 0603; CategoryPassive components inductor; File Size296KB，4 Pages; ManufacturerDelta Electronics; Environmental Compliance

Download Datasheet Parametric View All

0603CS-330EGTS Overview

General Purpose Inductor, 0.033uH, 2%, 1 Element, Ceramic-Core, SMD, CHIP, 0603

0603CS-330EGTS Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	Delta Electronics
Reach Compliance Code	compliant
ECCN code	EAR99
Is Samacsys	N
core material	CERAMIC
DC Resistance	0.22 Ω
Nominal inductance(L)	0.033 µH
Inductor Applications	RF INDUCTOR
Inductor type	GENERAL PURPOSE INDUCTOR
Number of functions	1
Number of terminals	2
Maximum operating temperature	125 °C
Minimum operating temperature	-40 °C
Minimum quality factor (at nominal inductance)	40
Maximum rated current	0.6 A
self resonant frequency	2300 MHz
Shape/Size Description	RECTANGULAR PACKAGE
shield	NO
surface mount	YES
Terminal location	DUAL ENDED
Terminal shape	WRAPAROUND
Test frequency	250 MHz
Tolerance	2%
Base Number Matches	1

Preview

Download Datasheet

View All

1. Part Description

1.1 Part Numbering (Example)

( Ex. )

0603

S-

120

T S

SIZE.

0402 1.0 * 0.5 mm

0603 1.6 * 0.8 mm

0805 2.0 * 1.2 mm

1008 2.5 * 2.0 mm

1206 3.2 * 1.6 mm

1210 3.2 * 2.5 mm

SHAPE.

C : C SHAPE

H : H SHAPE

M : MOLDING

PACK.

S=EIA RS481 CLEAR TAPE & REEL

PROFILE.

S: STANDARD

T: LOW PROFILE

Q:HIGH Q

TERMINALTYPE/MATERIAL.

A/T = Terminal

F = Ferrite Core (Substrate)

INDUCTANCE TOLERANCE.

INDUCTANCE.

1ST , 2ND , 3RD MULTIPLIER

G = ±2% , H = ±3% ,J = ±5% , K = ±10%

B=±

0.1n H , C=± 0.2n H , D=± 0.5 n H

SHAPE.

B=± 0.1n H ,

C=± 0.2n H ,

D=± 0.5 n H

E = FLAT TOP
