LAMINATED TRANSFORMERS
Type EI42 / 14.8
- 5VA
AGENCY
APPROVALS
1.
UL 506, File E113449
3.
EN61558
V
DE
Primary
(V)
230
230
230
230
230
230
230
230
Secondary
(V / mA)
6 / 834
9 / 556
12 / 417
15 / 334
18 / 278
24 / 208
2x6 / 417
2x9 / 278
2x12 / 208
No-Load Schematic
Voltage
(V)
No.
8.10
12.00
15.50
19.20
23.20
30.50
2x7.80
2x11.60
2x15.20
1
1
1
1
1
1
2
2
2
Part
Number
042-5381.0
042-5382.0
042-5383.0
042-5384.0
042-5385.0
042-5386.0
042-5387.0
042-5388.0
042-5389.0
Agency
Approvals
1/3*
1/3*
1/3*
1/3*
1/3*
1/3*
1/3*
1/3*
1/3*
Frequency 50/60Hz
Potted under vacuum
Split-bobbin
Temperature class ta 70°C/B
Weight: 0.2kg
Packaging unit: 15 pieces (tray)
230
230
2x15 / 167
2x19.40
2
042-5390.0
1/3*
*NOTE:
When checking the approval status of this product with VDE, add the prefix
"BV" and the suffix "G" to the orderable Part Number (these letters will also be found
on the part label).
The prefix and suffix are not part of the orderable Part Number.
Mechanical
(0.2)(0.3) (0.3) (0.2)
5
7,5
7,5 5
1 2
37
(1.46)
10
(0.39)
3
4
5
4,2
(0.165)
25
(1.00)
33
(1.30)
4
(0.16)
Pin Ø 0,8 mm
(Pin DIA. 0.031)
10 9
8
7 6
46
(1.81)
55
(2.17)
64
(2.52)
Schematics
No. 1
5
7
No. 2
5
6
7
9
1
9
1
10
USA 858 674 8100
•
Germany 49 7032 7806 0
•
Singapore 65 6287 8998
•
Shanghai
86 21 54643211 / 2
•
China 86 769 85538070
•
Taiwan 886 3 4641811
www.pulseeng.com
17
LT2007 (9/07)
LAMINATED TRANSFORMERS
Type EI48 / 16.8
- 10VA
AGENCY
APPROVALS
1.
UL 506, File E113449
3.
EN61558
V
DE
Primary
(V)
230
230
230
230
230
230
230
230
Secondary
(V / mA)
6 / 1666
9 / 1111
12 / 834
15 / 666
18 / 555
24 / 416
2x6 / 834
2x9 / 555
2x12 / 416
No-Load Schematic
Voltage
(V)
No.
7.90
12.00
15.70
19.20
22.90
30.60
2x7.90
2x12.00
2x15.70
1
1
1
1
1
1
2
2
2
Part
Number
048-5381.0
048-5382.0
048-5383.0
048-5384.0
048-5385.0
048-5386.0
048-5387.0
048-5388.0
048-5389.0
Agency
Approvals
1/3*
1/3*
1/3*
1/3*
1/3*
1/3*
1/3*
1/3*
1/3*
Frequency 50/60Hz
Potted under vacuum
Split-bobbin
Temperature class ta 40°C/B
Weight: 0.295kg
Packaging unit: 10 pieces (tray)
230
230
2x15 / 333
2x19.20
2
048-5390.0
1/3*
*NOTE:
When checking the approval status of this product with VDE, add the prefix
"BV" and the suffix "H" to the orderable Part Number (these letters will also be found
on the part label).
The prefix and suffix are not part of the orderable Part Number.
Mechanical
5
(5 x 0.2)
5 5 5 5
1 2
42,5
(1.67)
(0.39)
10
3
4
5
6
4,2
(0.165)
27,5
(1.08)
34,6
(1.36)
3,5
(0.14)
Pin Ø 0,8 mm
(Pin DIA. 0.031)
12 11 10 9
8
7
53,5
(2.10)
60
(2.36)
69
(2.72)
Schematics
No. 1
6
8
No. 2
6
7
8
11
1
11
1
12
USA 858 674 8100
•
Germany 49 7032 7806 0
•
Singapore 65 6287 8998
•
Shanghai
86 21 54643211 / 2
•
China 86 769 85538070
•
Taiwan 886 3 4641811
www.pulseeng.com
18
LT2007 (9/07)
LAMINATED TRANSFORMERS
Type EI54 / 18.8
- 16VA
AGENCY
APPROVALS
1.
UL 506, File E113449
3.
EN61558
V
DE
Primary
(V)
230
230
230
230
230
230
230
230
Secondary
(V / mA)
6 / 2666
9 / 1777
12 / 1333
15 / 1066
18 / 888
24 / 666
2x6 / 1333
2x9 / 888
2x12 / 666
No-Load Schematic
Voltage
(V)
No.
7.60
11.30
14.90
18.40
22.40
29.60
2x7.70
2x11.40
2x15.00
1
1
1
1
1
1
2
2
2
Part
Number
054-5381.0
054-5382.0
054-5383.0
054-5384.0
054-5385.0
054-5386.0
054-5387.0
054-5388.0
054-5389.0
Agency
Approvals
1/3*
1/3*
1/3*
1/3*
1/3*
1/3*
1/3*
1/3*
1/3*
Frequency 50/60Hz
Potted under vacuum
Split-bobbin
Temperature class ta 40°C/B
Weight: 0.43kg
Packaging unit: 10 pieces (tray)
230
230
2x15 / 533
2x18.70
2
054-5390.0
1/3*
*NOTE:
When checking the approval status of this product with VDE, add the prefix
"BV" and the suffix "K" to the orderable Part Number (these letters will also be found
on the part label).
The prefix and suffix are not part of the orderable Part Number.
Mechanical
(6 x 0.2)
5
5
5
5
5
5
4,2
(0.165)
1 2
51
(2.00)
37,5
(1.48)
3
4
5 6
7
30
(11.8)
14 13 12 11 10 9
8
10
(0.39)
59
(2.32)
65
(2.56)
38,8
(1.53)
3,5
(0.14)
Pin Ø 0,8 mm
(Pin DIA. 0.031)
75,3
(2.97)
Schematics
No. 1
7
9
No. 2
7
8
9
13
1
13
1
14
USA 858 674 8100
•
Germany 49 7032 7806 0
•
Singapore 65 6287 8998
•
Shanghai
86 21 54643211 / 2
•
China 86 769 85538070
•
Taiwan 886 3 4641811
www.pulseeng.com
19
LT2007 (9/07)
LAMINATED TRANSFORMERS
Type EI60 / 25.5
- 25VA
AGENCY
APPROVALS
V
3.
EN61558
D E
Primary
(V)
230
230
230
230
230
230
230
230
230
230
2x115
2x115
2x115
2x115
2x115
2x115
2x115
2x115
2x115
2x115
Secondary
(V / mA)
6 / 4170
9 / 2780
12 / 2080
15 / 1670
18 / 1390
24 / 1040
2x6 / 2080
2x9 / 1390
2x12 / 1040
2x15 / 830
6 / 4170
9 / 2780
12 / 2080
15 / 1670
18 / 1390
24 / 1040
2x6 / 2080
2x9 / 1390
2x12 / 1040
2x15 / 830
No-Load Schematic
Voltage
(V)
No.
6.90
10.30
13.60
17.00
20.50
27.00
2x6.90
2x10.50
2x13.60
2x17.30
6.90
10.30
13.60
17.00
20.50
27.00
2x6.90
2x10.50
2x13.60
2x17.30
1
1
1
1
1
1
2
2
2
2
3
3
3
3
3
3
4
4
4
4
Part
Number
060-0201.0
060-0202.0
060-0203.0
060-0204.0
060-0205.0
060-0206.0
060-0207.0
060-0208.0
060-0209.0
060-0210.0
060-0272.0
060-0273.0
060-0274.0
060-0275.0
060-0276.0
060-0277.0
060-0278.0
060-0279.0
060-0280.0
060-0281.0
Agency
Approvals
3*
3*
3*
3*
3*
3*
3*
3*
3*
3*
3*
3*
3*
3*
3*
3*
3*
3*
3*
3*
Frequency 50/60Hz
Potted under vacuum
Split-bobbin
Temperature class ta 40°C/B
Weight: 0.67kg
Packaging unit: 6 pieces (tray)
Mechanical
(6 x 0.2)
5
5
5
5
5
5
4,2
(0.165)
1
55
(2.165)
2
3
4
5 6
7
32,5
(1.28)
*NOTE:
When checking the approval status of this product with VDE,
add the prefix "BV" to the orderable Part Number (these letters
will also be found on the part label).
The prefix is not part of the
orderable Part Number.
43,5
(1.71)
14 13 12 11 10 9 8
11,2
(0.44)
66
(2.60)
72,5
(2.85)
49,2
(1.94)
4
(0.16)
Pin Ø 0,8 mm
(Pin DIA. 0.031)
81,5
(3.21)
Schematics
No. 1
7
9
No. 2
7
8
9
13
1
13
1
14
No. 3
7
5
3
1
13
9
No. 4
7
5
3
1
8
9
13
14
USA 858 674 8100
•
Germany 49 7032 7806 0
•
Singapore 65 6287 8998
•
Shanghai
86 21 54643211 / 2
•
China 86 769 85538070
•
Taiwan 886 3 4641811
www.pulseeng.com
20
LT2007 (9/07)
LAMINATED TRANSFORMERS
Type EI66 / 23
- 36VA
Primary
(V)
Secondary
(V / mA)
6 / 6000
9 / 4000
12 / 3000
15 / 2400
18 / 2000
24 / 1500
2x6 / 3000
2x9 / 2000
2x12 / 1500
2x15 / 1200
6 / 6000
9 / 4000
12 / 3000
15 / 2400
18 / 2000
24 / 1500
2x6 / 3000
2x9 / 2000
2x12 / 1500
2x15 / 1200
No-Load Schematic
Voltage
(V)
No.
6.90
10.30
13.60
17.00
20.50
27.00
2x6.90
2x10.50
2x13.60
2x17.30
6.90
10.30
13.60
17.00
20.50
27.00
2x6.90
2x10.50
2x13.60
2x17.30
1
1
1
1
1
1
2
2
2
2
3
3
3
3
3
3
4
4
4
4
Part
Number
066-0131.0
066-0132.0
066-0133.0
066-0134.0
066-0135.0
066-0136.0
066-0137.0
066-0138.0
066-0139.0
066-0140.0
066-0226.0
066-0227.0
066-0228.0
066-0229.0
066-0230.0
066-0231.0
066-0232.0
066-0233.0
066-0234.0
066-0235.0
Agency
Approvals
3*
3*
3*
3*
3*
3*
3*
3*
3*
3*
3*
3*
3*
3*
3*
3*
3*
3*
3*
3*
AGENCY
APPROVALS
V
3.
EN61558
D E
230
230
230
230
230
230
230
230
230
230
2x115
2x115
2x115
2x115
2x115
2x115
2x115
2x115
2x115
2x115
Frequency 50/60Hz
Potted under vacuum
Split-bobbin
Temperature class ta 40°C/B
Weight: 0.75kg
Packaging unit: 6 pieces (tray)
Mechanical
5
5
(7 x 0.2)
5 5 5
5
5
4,2
(0.165)
1 2 3
4
5
6
7
8
*NOTE:
When checking the approval status of this product with VDE,
add the prefix "BV" and the suffix "A" to the orderable Part Number
(these letters will also be found on the part label).
The prefix and
suffix are not part of the orderable Part Number.
35
(1.38)
(2.40)
(1.87)
47,5
61
16 15 14 13 12 11 10 9
(0.425)
10,8
71
(2.80)
77,5
(3.05)
48,5
(1.91)
4,5
(0.18)
Pin Ø 0,8 mm
(Pin DIA. 0.031)
87,2
(3.43)
Schematics
No. 1
8
10
No. 2
8
9
10
15
1
15
1
16
No. 3
8
6
3
1
15
10
No. 4
8
6
3
1
9
10
15
16
USA 858 674 8100
•
Germany 49 7032 7806 0
•
Singapore 65 6287 8998
•
Shanghai
86 21 54643211 / 2
•
China 86 769 85538070
•
Taiwan 886 3 4641811
www.pulseeng.com
21
LT2007 (9/07)
