RGP15A......RGP15MT
1.5 Amp. Glass Passivated Fast Recovery Rectifier
Dimensions in mm.
DO-15
(Plastic)
Voltage
50 to 1000 V.
Current
1.5 A. at 55 °C.
®
6.35
± 0.2
58.5
± 0.5
Mounting instructions
1. Min. distance from body to soldering point,
4 mm.
2. Max. solder temperature, 350 °C.
3. Max. soldering time, 3.5 sec.
4. Do not bend lead at a point closer than
2 mm. to the body.
•
Glass passivated junction
•
High current capability
•
The plastic material carries
U/L recognition 94 V-0
•
Terminals: Axial Leads
•
Polarity: Color band denotes cathode
Maximum Ratings, according to IEC publication No. 134
RGP RGP RGP RGP RGP RGP RGP RGP RGP
15A 15B 15D 15G 15J 15K 15KT 15M 15MT
V
RRM
Peak recurrent reverse voltage (V)
I
F(AV)
Forward current at Tamb = 55 °C
I
FRM
Recurrent peak forward current
I
FSM
8.3 ms. peak forward surge current
(Jedec Method)
50
100 200
400
600 800 800
1000 1000
1.5 A
10 A
50 A
150 ns
250 ns 500 ns 300 ns 500 ns 300 ns
– 65 to + 175 °C
– 65 to + 175 °C
20 mJ
t
rr
T
j
T
stg
E
RSM
Max. reverse recovery
time from
I
F
= 0.5 A
I
R
= 1 A
I
RR
= 0.25 A
Operating temperature range
Storage temperature range
Maximum non repetitive peak
reverse avalanche energy.
I
R
= 1A ; T
J
= 25 ºC
Electrical Characteristics at Tamb = 25 °C
V
F
I
R
R
thj-a
Max. forward voltage drop at I
F
= 1.5 A
at 25
o
C
Max. reverse current at V
RRM
at 150
o
C
Thermal resistance (I = 10 mm.) Max.
Typ.
1.3 V
5µA
200 µ A
50 °C/W
30 °C/W
Nov - 02
RGP15A......RGP15MT
Rating And Characteristic Curves
TYPICAL FORWARD CHARACTERISTIC
FORWARD CURRENT DERATING CURVE
10
2.5
10 mm. - 10 mm.
2
1
1.5
0.1
T
j
= 25 °C
1
0.5
0.01
0.6
0
0.8
1
1.2
1.4
1.6
0
25
50
75 100 125 150 175
Tamb, ambient temperature (ºC)
V
F '
instantaneous forward voltage (V)
MAXIMUM NON REPETITIVE
PEAK FORWARD SURGE CURRENT
TYPICAL JUNCTION CAPACITANCE
50
100
40
30
10
20
T
j
= 25ºC
f = 1 MHz
10
0
1
2
4 6 10
20
40
100
Number of cycles at 60 Hz.
1
1
5
10
50
100
V
R
reverse voltage (V)
Nov - 02
