WRAPOST RECEPTACLES
for .015” - .025” diameter pins
M
ON
S
I
CHI
A
PINS
NE
D
1702/1703
Basic Part
Number
# of
Wraps
Length
A
⇒
⇒
0038⇒0040/0066⇒0068
1702-2
1703-3
2
3
.370
.510
Basic
Part #
0040-1
0039-2
0038-3
0068-1
0067-2
0066-3
# of
Length
Wraps
A
.260
1
.360
2
.500
3
.260
1
.360
2
.500
3
Dia.
C
.072
.062
170X-X-17-XX-30-XX-02-0
Press-fit in .057 mounting hole
00XX-X-17-XX-30-XX-02-0
Press-fit in .055 mounting hole
0086/0088/0089
Basic Part
Number
0089-2
0088-3
0086-4
# of
Wraps
2
3
4
Length
A
.370
.510
.630
⇒
1030⇒1036
Basic
Part #
1032-1
1031-2
1030-3
1036-1
1035-2
1034-3
# of
Length
Wraps
A
1
.260
2
.360
3
.510
1
.260
2
.360
3
.510
Dia.
C
.072
.062
008X-X-17-XX-3X-XX-02-0
Press-fit in .057 mounting hole
103X-X-17-XX-3X-XX-02-0
Press-fit in .057 mounting hole
1045
1040
1045-3-17-XX-30-XX-02-0
Press-fit in .043 mounting hole
1040-3-17-XX-30-XX-02-0
Press-fit in .056 mounting hole
SPECIFICATIONS
SHELL MATERIAL:
Brass Alloy 360, 1/2 Hard
CONTACT MATERIAL:
Beryllium Copper Alloy 172, HT
DIMENSION IN INCHES
TOLERANCES ON:
LENGTHS:
±.005
DIAMETERS: ±.002
ANGLES:
± 2°
ORDER CODE: XXXX - X - 17 - XX - XX - XX - 02 - 0
BASIC PART #
SPECIFY SHELL FINISH:
01
200μ” TIN/LEAD OVER NICKEL
80
200μ” TIN OVER NICKEL (RoHS)
15
10μ” GOLD OVER NICKEL (RoHS)
2002/95/EC
SPECIFY CONTACT FINISH:
02
100μ” TIN/LEAD OVER NICKEL
84
100μ” TIN OVER NICKEL (RoHS)
27
30μ” GOLD OVER NICKEL (RoHS)
RoHS
SELECT CONTACT
#30 or #32
CONTACT (DATA ON PAGE 219)
w w w. m i l l - m a x . c o m
166
516-922-6000
