Model 1210
Process Control
PC Board Mountable Pressure Sensor
0-100 mV Output
Gage, Differential and Absolute
Temperature Compensated
Medical Instrumentation
HVAC
Barometric Pressure
Air Flow Management
Avionics
DESCRIPTION
The Model 1210 is a temperature compensated, piezoresistive
silicon pressure sensor packaged in a dual-in-line configuration.
It is intended for cost sensitive applications where excellent
performance and long-term stability are required.
Integral temperature compensation is provided over a range
of 0-50°C using laser-trimmed resistors. An additional laser-
trimmed resistor is included to normalize pressure sensitivity
variations by programming the gain of an external differential
amplifier. This provides sensitivity interchangeability of ±1%.
Gage, absolute, and differential pressure ranges from 0-2
PSI to 0-100 PSI are available. Multiple lead and tube
configurations are also available for customizing the package for
specific applications.
Please refer to the low pressure section for information on
FEATURES
Dual-in-line Package
±0.1% Non-linearity
±0.5% Temperature Performance
1.0% Interchangeable Span
(provided by gain set resistor)
Solid State Reliability
Low Power
products with operating pressures less than 0-2 PSI. For a
compensated sensor using a current set resistor as opposed to a
gain set resistor, please refer to the Model 1220.
DIMENSIONS
STANDARD RANGES
Range
0 to 2
0 to 5
0 to 15
0 to 30
0 to 50
0 to 100
psia
psid
psig
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
1-14
HITs – Standard
PC Board Mountable Pressure Sensor
PERFORMANCE SPECIFICATIONS
Supply Current: 1.5mA
Ambient Temperature: 25°C (Unless otherwise specified)
PARAMETERS
Full Scale Output Span
Zero Pressure Output
Pressure Non-linearity
Pressure Hysteresis
Input & Output Resistance
Temperature Error - Span
Temperature Error - Zero
Thermal Hysteresis - Zero
Supply Current
Response Time
Output Noise
Output Load Resistance
Insulation Resistance (50 VDC)
Pressure Overload
Operating Temperature
Storage Temperature
Media
Weight
Notes
1. For 2 psi, output span is 30-60mV.
2.
Compensation resistors are an integral part of the sensor package; no
additional external resistors are required. Pins 7 and 8 must be kept
open.
Best Fit Straight Line.
Temperature range: 0-50°C in reference to 25°C.
Guarantees input/output ratiometricity.
For a zero-to-full scale pressure step change.
10 Hz to 1kHz.
-40°C to +125°C
-50°C to +150°C
Non-corrosive Gases Compatible with Wetted Materials
3 Grams
2
50
3X
2500
0.05
0.01
4400
0.3
0.1
0.1
1.5
1.0
1.0
2.0
MIN
75
TYP
100
MAX
150
2
0.1
0.1
6000
0.5
0.5
UNITS
mV
±mV
Model 1210
NOTES
1
2
3
±% Span
±% Span
Ω
±% Span
±% Span
±% Span
mA
msec
µV
p-p
MΩ
MΩ
Rated
2, 4
2, 4
5
6
7
8
9
10
8.
9.
Prevents increase of TC-Span due to output loading.
3X or 200 psi maximum, whichever is less. 20 psi for 2 psi and 5 psi
versions.
10. Wetted materials are glass, ceramic, silicon, RTV, nickel, and aluminum.
11. Soldering of lead pins: 250°C for 5 seconds, maximum.
12. Tube length: L=470 ± 5 mil, S=300 ± 3 mil, N=no tube.
13. Lead pins can either be in the same or the opposite direction as the
pressure tube. See Dimensions drawing for lead configurations.
3.
4.
5.
6.
7.
CONNECTIONS
ORDERING INFORMATION
1210 A - 015 G - 3 S
Pressure Tubes (L, S, N - see note 12)
Lead Configuration (1, 3 - see note 13)
Type (G = Gage, A = Absolute, D = Differential)
Pressure Range
Grade
Model
APPLICATION SCHEMATIC
April 2000
HITs – Standard
1-15
