INTERCONNECTS
SERIES 321, 322, 323, 324 • .100” GRID WRAPOST •
SINGLE ROW STRIPS
•
Wraposts available in 1 - 4 levels using MM
pin numbers:
1-Level uses pin # 0040-1
2-Level uses pin # 0089-2
3-Level uses pin # 0088-3
4-Level uses pin # 0086-4
See page 198 for details
.015-.025
.010 .018
.098
.110
.160
.200
•
Hi-Rel, 4- nger BeCu #30 contact is rated at
.025
SQUARE
.260
3 amps. See page 253 for details
•
Insulators are high temperature thermoplastic,
FIG. 1
.015-.025
.010 .018
suitable for all soldering operations
ORDERING INFORMATION
Series 321...001
1 Level Wrapost
321 13 1_ _ 41 001000
Specify number of pins
01-64
.193
.098
.110
.160
FIG. 1
Series 322...001
.025
SQUARE
.370
2 Level Wrapost
322 XX 1_ _ 41 001000
FIG. 2
.015-.025
.010 .018
FIG. 2
Series 323...001
.193
Specify number of pins
01-64
3 Level Wrapost
323 XX 1_ _ 41 001000
.098
.110
.160
FIG. 3
Series 324...002
Specify number of pins
.025
SQUARE
.510
01-64
4 Level Wrapost
324 XX 1_ _ 41 002000
FIG. 4
FIG. 3
.015-.025
.010 .018
Specify number of pins
01-64
.098
.110
.160
.193
2011/65/EU
.025
SQUARE
.630
RoHS - 2
XX=Plating Code
See Below
11
10
µ”
Au
10
µ”
Au
For
Electrical, Mechanical
& Enviromental Data,
See page 264
SPECIFY PLATING CODE XX=
13
30
µ”
Au
91
10
µ”
Au
93
30
µ”
Au
41
10
µ”
Au
43
200
µ”
Sn
30
µ”
Au
FIG. 4
Sleeve (Pin)
Contact (Clip)
10
µ”
Au
200
µ”
Sn/Pb 200
µ”
Sn/Pb
200
µ”
Sn
Mill-Max Mfg. Corp. • 190 Pine Hollow Road, P.O. Box 300, Oyster Bay, NY 11771 • 516-922-6000 • Fax: 516-922-9253 • www.mill-max.com
PAGE 69 | INTERCONNECTS
