Digital
Telecom
Conexant HDSL recommendations
EP13-SMD
Features
•
RoHS compatible versions available
•
Designed for Conexant chipsets
•
Good total harmonic distortion
characteristics
•
Optimized for size and performance
•
Customization available
•
For IC approval status, contact
Midcom
•
135 Ohm Line Impedance
•
Designed to meet IEC950
requirements
EP13-TH
EPX9-SMD
EPX7-SMD
Part Number
Chip Set
51719R
Octane, G24
51715R
Octane, G24
51576R
Orion
RS8973
50430R
BT8970, BT8921
RS8973
50050
BT8970, BT8921
51062R
RS8973
50772
RS8973
RS8973
671-7928
BT8970, BT8921
50051
BT8970, BT8921
Application
SHDSL CO with EL1508 Line Driver
SHDSL CO with Le87213/A or Le87220 Line Driver
SHDSL CO & CPE
All Rates
1168 Kbps and below
All Rates
1168 Kbps and below
All Rates Improved THD
All Rates Improved THD
All Rates
1168 Kbps and below
784 Kbps and below
Insulation
Basic
Basic
Supplementary
Supplementary
Supplementary
Supplementary
Supplementary
Functional
Supplementary
Turns Ratio
0.7:1
0.472:1
5.4:1
2:1
2:1
2:1
2:1
2:1
2:1
Inductance
3.2 mH
3.18 mH
3 mH
2 mH
2 mH
2 mH
2 mH
2 mH
2 mH
Package
EPX9
EPX7
EP13 SMD
EP13 SMD
EP13 TH
EP13 SMD
EP13 TH
EP13 SMD
EP13 TH
Schematic
2
2
1
1
1
1
1
1
1
PRI
(Line)
SEC
(Device)
Schematic 1
Midcom, Inc. USA
121 Airport Drive – PO Box 1330
Watertown, SD 57201
T: 605.886.4385 ~ F: 605.886.4486
www.midcom-inc.com ~ email:sales@midcom-inc.com
Schematic 2
Midcom, Inc. China
10/F Spectrum Tower 53 Hung to Road
Kwun Tong, Kowloon, HK
T: 852.2320.4221 ~ F: 852.2352.3272
email: asiasales@midcom-inc.com
10/19/2006
Details subject to change. Contact your Midcom sales representative for additional information. Dimensions: in/mm. All tolerances are
±.010/0,25
and electrical specifications are @25°C unless otherwise specified.
