DB101
THRU
DB107
1 Amp Single Phase
Glass Passivated
Bridge Rectifier
50 to 1000 Volts
DB-1
Notch
•
Features
Lead Free Finish/Rohs Compliant (Note1) ("P"Suffix designates
Compliant. See ordering information)
4-PIN DIP
Package
Glass Passivated Diode Construction
UL Recognized File # E165989
High Surge Current Capability
Epoxy meets UL 94 V-0 flammability rating
Moisture Sensitivity Level 1
Halogen
free available upon request by adding suffix "-HF"
Operating Junction Temperature: -55°C to +150°C
Storage Temperature: -55°C to +150°C
Thermal Resistance : Rthja: 40C/W;RthJL:15C/W.
MCC
Catalog
Number
Device
Marking
Maximum
Recurrent
Peak Reverse
Voltage
50V
100V
200V
400V
600V
800V
1000V
Maximum
RMS
Voltage
Maximum
DC
Blocking
Voltage
50V
100V
200V
400V
600V
800V
1000V
•
•
•
•
•
•
•
•
•
•
Maximum Ratings
B
-
~
A
+
C
~
DB101
DB102
DB103
DB104
DB105
DB106
DB107
DB101
DB102
DB103
DB104
DB105
DB106
DB107
35V
70V
140V
280V
420V
560V
700V
E
F
G
D
H
Electrical Characteristics @ 25 Unless Otherwise Specified
°C
Average Forward
Current
Peak Forward Surge
Current
Maximum
Instantaneous
Forward Voltage
Maximum DC
Reverse Current At
Rated DC Blocking
Voltage
Typical Junction
Capacitance
I
F(AV)
1A
T
A
= 40°C
DIMENSIONS
I
FSM
30A
8.3ms, half sine
DIM
A
B
C
D
E
F
G
H
MIN
.316
.245
.300
.236
.102
INCHES
MM
V
F
1.1V
I
FM
= 1.0A;
T
J
= 25°C
MAX
.335
.255
.350
.299
.130
.060
.022
.205
MIN
8.05
6.20
7.60
6.01
2.60
1.50
.41
5.00
MAX
8.51
6.50
8.90
7.60
3.30
.56
5.20
NOTE
I
R
10µA
0.5mA
T
J
= 25°C
T
J
= 125°C
.016
.195
Typ
Typ
C
J
25pF
Measured at
1.0MHz, V
R
=4.0V
Notes:1.High Temperature Solder Exemption Applied, see EU Directive Annex 7.
Revision:
C
www.mccsemi.com
1 of 3
2014/03/05
DB101 thru DB107
Figure
1
Typical Forward
Characteristics
20
10
6
4
2
Amps
1
.6
.4
.2
.1
.06
.04
.02
.01
.4
.6
.8
Volts
Instantaneous Forward Current -
Amperesversus
Instantaneous Forward Voltage -
Volts
1.0
1.2
1.4
25°C
100
60
40
20
10
6
4
2
µAmps 1
.6
.4
.2
.1
.06
.04
.02
.01
20
40
60
MCC
Figure
2
Typical Reverse
Characteristics
TM
Mic Commercial
Components
ro
T
J
=25°C
80
Volts
100
120
140
Instantaneous Reverse Leakage Current -
MicroAmperes
ersus
v
Percent Of Rated Peak Reverse Voltage -
Volts
Figure 3
Forward Derating Curve
1.2
60
50
40
30
0.6
Amps
0.4
Amps
20
10
Figure
4
Peak Forward Surge
Current
1.0
0.8
0
0.2
Single Phase, Half Wave
60Hz Resistive or Inductive Load
0
0
25
50
75
100
125
150
1
2
4
6
8 10
Cycles
Peak Forward Surge Current -
Amperesversus
Number Of Cycles At 60Hz -
Cycles
20
40
60 80
100
Average Forward Rectified Current - Ambient Temperature -
qC
www.mccs
emi.com
Revision:
C
2 of 3
2014/03/05
MCC
Micro Commercial Components
TM
Ordering Information :
Device
Part Number-BP
Note : Adding "-HF" suffix for halogen free, eg. Part Number-BP-HF
Packing
Bulk: 2.5Kpcs/Box
