LC0603
Ceramic
Core
C
(max)
E
A
(max)
Pad
Layout
B
G
H
J
F
E
H
D
APPLICATIONS
n
LC resonant circuits such as oscillators and signal generators
n
Impedance matching
n
Circuit isolation
n
RF filters
n
Disk drives and computer peripherals
n
Audio eduipment
n
Video equipment
n
TV and radio
n
Telecommunication equipment
CHARACTERISTICS
DIELECTRIC STRENGTH:
500 Volts RMS at sea level.
OPERATING TEMPERATURE:
-25°C to +85°C.
STORAGE TEMPERATURE:
-45°C to +100°C in original tape and
reel package.
SOLDERING HEAT RESISTANCE:
250°C for 10 seconds after
120°C preheat cycle for 5 minutes.
SOLDERABILITY:
Terminals are covered 95% with solder
RESISTANCE TO SOLVENT:
No change in appearance when
dipped into alcohol or freon for 3 minutes.
MARKING:
Marked with inductance value in EIA code.
Notes:
(1) Available tolerances: (G) 2%, (J) 5%, (K) 10%, (M) 20%.
(2) Q measured using HP4286A RF Impedance Analyzer with HP16193A Test Fixture.
(3) Rdc measured using HP4286A.
(4) SRF measured using HP8753D Network Analyzer.
(5) Packaging: Tape and reel 4,000 pieces per reel.
B
C
A
MAX. MAX. MAX.
1.57
0.062
1.02
0.040
0.92
0.036
D
E
F
0.86
0.034
G
H
J
0.76
0.030
0.33
0.013
1.02
0.040
0.64
0.025
0.64
0.025
L vs Frequency
100
12nH
39nH
10
L (nH)
100nH
1
0
1
10
1000
100
Frequency (MHz)
10000
PART
NUMBER (1)
LC0603-1N8
LC0603-3N9
LC0603-5N8
LC0603-100
LC0603-120
LC0603-150
LC0603-180
LC0603-220
LC0603-270
LC0603-330
LC0603-390
LC0603-470
LC0603-560
LC0603-680
LC0603-720
LC0603-820
LC0603-101
LC0603-111
LC0603-121
14
INDUCTANCE
(nH)
1.8
3.9
5.8
10
12
15
18
22
27
33
39
47
56
68
72
82
100
110
120
Q
MINIMUM
(2)
4
9
16
28
21
22
24
27
35
33
32
34
33
37
35
39
36
45
48
TEST
FREQUENCY
(MHz)
250
250
250
250
250
250
250
250
250
250
250
200
200
200
150
150
150
150
150
DC RESISTANCE
OHMS
MAX (W) (3)
.07
.07
.08
.09
.12
.25
.25
.15
.16
.23
.27
.49
.35
.39
.53
.58
.80
.86
.92
RATED DC
CURRENT MAX
(mA)
700
700
700
700
700
700
700
700
600
600
600
600
600
600
400
400
400
300
300
SELF RESONANT
FREQUENCY
(MHZ) (4)
8000
7240
6938
6636
5091
4752
3659
3267
2959
2652
2454
2321
2228
2002
1844
1851
1625
1505
1451
ISI 1-800-854-1881
