F-219
IPBT–105–H2–T–D–K
IPBT–108–H1–T–D–RA–K
(4.19 mm) .165"
IPBT–105–H1–T–D–GP
IPBT SERIES
ISOLATED TERMINAL POWER HEADER
SPECIFICATIONS
For complete specifications
see www.samtec.com?IPBT
Insulator Material:
Black Liquid Crystal Polymer
Contact Material:
High Copper Alloy
Plating:
Sn over 50 µ" (1.27 µm) Ni
Operating Temp Range:
-55 °C to +105 °C
Voltage Rating:
400 VAC/565 VDC
Standard Creepage:
(3.66 mm) .144" (-S)
(3.63 mm) .143" (-D)
Standard Clearance:
(3.05 mm) .120"
RoHS Compliant:
Yes
Lead–Free Solderable:
Yes
IPBT/IPBS
CURRENT
PINS
RATING
POWERED (PER CONTACT)
2
4
6
8
30
10.3 A
8.4 A
7.6 A
7.1 A
6.0 A
Board Mates:
IPBS
Cable Mates:
PMSD, PMSS
Latching mechanism
for mating with
IPBD Series
Keyed
polarization
CREEPAGE
AND CLEARANCE
Selectively loading
contacts achieves customer
specific creepage and
clearance requirements.
Contact asp@samtec.com
Individually
shrouded pins
• Individually
shrouded contacts
• Polarized guide
post hole option
IPBT
1
NO. OF POSITIONS
PER ROW
LEAD
STYLE
PLATING
OPTION
ROW
OPTION
OPTION
RECOGNITIONS
For complete scope
of recognitions see
www.samtec.com/quality
02, 03, 04, 05, 08, 10, 15
(–D only)
= Through-hole
–H1
FILE NO. E111594
02, 03, 04, 05, 08, 10
(–S only)
(Standard sizes)
= Surface Mount
–H2
= Matte
Tin
–T
= Single
Row
–S
= Double
Row
–D
= Right-angle
(Lead Style
–H1 only)
–RA
APPLICATION
IPBS
MATED
HEIGHT
(10.29)
.405
= Guide
Post Holes
(Not available
with –K)
(9.65)
.380
(3.30)
.130
–GP
IPBT
– H1–S
(1.14) .045 SQ
No. of Positions x (4.19) .165 + (1.33) .052
–H1–D
(11.43)
.450
15
IPBT/IPBS
MATED
LEAD STYLE HEIGHT*
(15.25) .600
H1/–01
(16.84) .663
–H2/–02
*Processing conditions
will affect mated height.
01
(11.40)
.449
02
(6.58)
.259
16
(9.60) (1.27)
.378 .050
30
(15.62)
.615
= Keyed
Polarization
(not available
with -GP
option, is
required
callout if -GP
not called out)
–K
– H2–S
(4.19)
.165
No. of Positions x (4.19) .165 + (12.27) .483
No. of Positions x (4.19) .165 + (6.10) .240
–H2–D
(5.51)
.217
ALSO AVAILABLE
(MOQ Required)
• Other sizes
• Other lead styles
Note:
Some lengths, styles and
options are non-standard,
non-returnable.
(1.52)
.060
(3.73) .147
(6.58)
.259
01
02
15
(3.73) .147
(10.77)
.424
16
–H1–S–RA
(3.43)
.135 DIA
(5.21)
.205
–GP OPTION
(4.06) .160
30
(1.52)
.060
–H1–D–RA
Due to technical progress, all designs, specifications and components are subject to change without notice.
All parts within this catalog are built to Samtec’s specifications.
Customer specific requirements must be approved by Samtec and identified in a Samtec customer-specific drawing to apply.
