Conformal
Coated Inductors
.29" max
24 AWG/TCW
1.15" nominal
LD1
.110"
These axial-leaded inductors have a uniform, conformal coating which makes them ideal for automa tic insertion.
INDUCTANCES .10µH to 1,000µH
OPERATING TEMPERATURE RANGE -55•C to +105•C.
CURRENT RATING Based on 0.25 w power dissipation.
att
INDUCTANCE TOLERANCE ±10%overentire inductance range.
Tolerances of 5% available by special order.
DIELECTRIC WITHSTANDING VOLTAGE 1,000 Vrms, Sea Level.
PART
NUMBER
LD1-R10K
LD1-R12K
LD1-R15K
LD1-R18K
LD1-R22K
LD1-R27K
LD1-R33K
LD1-R39K
LD1-R47K
LD1-R56K
LD1-R68K
LD1-R82K
LD1-1R0K
LD1-1R2K
LD1-1R5K
LD1-1R8K
LD1-2R2K
LD1-2R7K
LD1-3R3K
LD1-3R9K
LD1-4R7K
LD1-5R6K
LD1-6R8K
LD1-8R2K
LD1-100K
LD1-120K
LD1-150K
LD1-180K
LD1-220K
LD1-270K
LD1-330K
LD1-390K
LD1-470K
LD1-560K
LD1-680K
LD1-820K
LD1-101K
LD1-121K
LD1-151K
LD1-181K
LD1-221K
LD1-271K
LD1-331K
LD1-391K
LD1-471K
LD1-561K
LD1-681K
LD1-821K
LD1-102K
TERMINAL PULL 5lbs.
TESTING Inductance and Q measured withQ meter HP4342A
at specified frequency. DCR measured with Milliohm meter.
SRF measured on HP4191A.
MARKING 4 bands EIA color code.
PACKAGING Bulk or Tape and Reel.
SELF RESONANT
FREQUENCY
MINIMUM (MHz)
680.0
640.0
600.0
550.0
510.0
430.0
410.0
365.0
330.0
300.0
275.0
250.0
230.0
150.0
140.0
125.0
115.0
100.0
90.0
80.0
75.0
65.0
60.0
55.0
50.0
40.0
35.0
30.0
25.0
20.0
24.0
22.0
20.0
18.0
15.0
14.0
13.0
12.0
11.0
10.0
9.0
8.0
7.0
6.5
6.0
5.0
4.2
3.8
3.4
INDUCT ANCE
µH ± 10%
.10
.12
.15
.18
.22
.27
.33
.39
.47
.56
.68
.82
1.0
1.2
1.5
1.8
2.2
2.7
3.3
3.9
4.7
5.6
6.8
8.2
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
270
330
390
470
560
680
820
1000
Q
MINIMUM
40
40
38
35
33
33
30
30
30
30
28
28
25
25
28
30
30
37
45
45
45
50
50
55
55
45
45
50
50
50
45
45
45
45
50
50
50
30
30
30
30
30
30
30
30
30
30
30
30
TEST
FREQUENCY
(MHz)
25.0
25.0
25.0
25.0
25.0
25.0
25.0
25.0
25.0
25.0
25.0
25.0
25.0
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
.79
.79
.79
.79
.79
.79
.79
.79
.79
.79
.79
.79
DC RESIST ANCE
OHMS
MAXIMUM (Ω )
.08
.09
.10
.12
.14
.16
.22
.30
.35
.50
.60
.85
1.00
.18
.22
.30
.40
.55
.85
1.00
1.20
1.80
2.00
2.70
3.30
2.70
2.80
3.10
3.30
3.50
3.40
3.60
4.50
5.70
6.70
7.30
8.00
13.00
15.00
17.00
21.00
25.00
28.00
35.00
42.00
46.00
60.00
65.00
72.00
RATED DC
CURRENT MAX
(mA)
1380
1300
1230
1120
1040
975
830
710
660
550
500
420
390
620
560
480
415
355
285
263
239
195
185
160
144
160
157
149
144
140
130
125
110
100
92
88
84
66
61
57
52
47
45
40
36
35
30
29
28
