CTS
Reeves
FREQUENCY PRODUCTS
Model 322
DIP VCXO
CRYSTALS
Features:
•
•
•
•
•
•
Frequency Range 1 to 100 MHz
Low Cost
Internal SMT Construction
HCMOS/TTL Compatible
14 Pin DIP Compatible Package
Standard Frequencies
CLOCKS
The CTS Reeves Model 322 is a low cost
VCXO, enclosed in a 14 Pin DIP Package for
use in Phase Lock Loop Applications. It's
small size means more application flexibility.
The Model 322 is available with a variety of
pullability and stability options and is useful
in almost any VCXO application. Low noise
means superior jitter performance in
communication applications.
VCXOs
Electrical Specifications:
Parameter
Maximum
Supply Voltage
Operating
Current (ma.)
1
Output Type
Fanout
1
Rise and Fall Times
1
0.8 Vdc to +2.4 Vdc
Aging
1st Year
1
(PPM)
10 Years
1
Duty Cycle in %
Voltage Stability
1
PPM Over Supply Range
Start Up Time (ms.)
Control Voltage
Input Impedance
A, B, & C Deviation
Linearity
D Deviation
Deviation Response at -3 dB
Deviation Slope
Notes:
1.0 to < 12
35
HCMOS
< 7 ns
3
12
50
±5
5
10
Frequency Range (MHz)
12 to < 25
25 to < 30
7 Vdc
5 Vdc
±5%
25
35
TTL
TTL
5 TTL (25pf)
< 7 ns
4
12
50
±10
5
< 5 ns
5
15
50
±10
5
30 to < 100
75
HCMOS
< 3 ns
7
18
50
±10
6
8
TCXOs
10
8
0.5 to 4.5 Vdc
100 K Minimum
±10%
of Best Straight Line
±20%
of Best Straight Line
10 kHz Min.
Positive
OCXOs
1 - Values stated in the table are maximum
2 - Frequency Stability is referred to the frequency at +25°
3 - Center Frequency occurs between +0.5 Vdc. & +4.5 Vdc.
171 COVINGTON DRIVE
•
BLOOMINGDALE,
IL
60108
Phone:
630-924-3500
•
Fax:
630-924-6610
61
CTS
Reeves
CRYSTALS
FREQUENCY PRODUCTS
Model 322
DIP VCXO
Waveform Conditions:
Period (100%)
% Uptime
CMOS
(100%)
+2.4V
(90%)
+1.5V
(50%)
+0.5V
(10%)
t
f
t
f
TTL
Equivalent Test Load:
Vcc
Out
Ground
Test
Point
HI-Z
Probe
5 TTL LOADS
5V
Vcc
CR1
500 OHM
NOM.
CR2
CR3
Voh
Vol
15 pf
.01uF
CR4
CLOCKS
CR1-CR4 are IN3064
Note: Do Not Use TTL Load For CMOS Measurements
Outline Drawing and Pin
Connections:
.200 Max
1
14
.600
.0185 DIA
.200 LG MIN (TYP)
.03 Max
.805 Max
7
8
.300
.505 Max
Pin Connections
PIN
1
7
8
14
FUNCTION
AFC
Case/CKT GND
Output
+5 VDC
VCXOs
STANDOFFS
Mechanical Specifications:
Case:
Metal, hermetically sealed
Leads:
Nickel plated with solder coating,
or gold plated
Seal:
Resistance weld
Fine Leak Test:
Mass spectrometer leak rate less than
5x10
-8
atmosphere-cc/sec of helium
Solderability:
95% solder coverage, using RMA flux
63 Sn / 37 Pb solder at +245°C
±5°C
Temperature:
Operating: See Chart
Storage: -55 to 125°C
Vibration:
20 G's rms, 20 to 2000 Hz
Mechanical Shock:
1000 G's 5ms pulse (3 shock/plane)
TCXOs
Ordering Information:
Model Type 322 - ___ ___MO___ ___ . ___ ___ ___ ___ ___ ___
Temperature Stability Options
Frequency Deviation Options
A
B
C
D
±50
ppm to
±90
ppm
±75
ppm to
±135
ppm
±100
ppm to
±180
ppm
±200
ppm to
±360
ppm
Frequency in MHz
OCXOs
A
B
C
D
±20
ppm
0°C to + 70°C
±50
ppm
0°C to + 70°C
±25
ppm
-20°C to + 70°C
±25
ppm
-40°C to + 85°C
62
171 COVINGTON DRIVE
•
BLOOMINGDALE,
IL 60108
Phone:
630-924-3500
•
Fax:
630-924-6610
