LV426112
circuit breaker Compact NSXm 32A 4P 16kA at
380/415V(IEC) EverLink lug
Main
Range
Product name
Device short name
Product or component type
Device application
Compact
Compact NSXm
NSXm 32E
Circuit breaker
Distribution
Protection
Complementary
[In] rated current
Poles description
Neutral position
Control type
Mounting mode
Network type
Network frequency
Breaking capacity code
[Icu] rated ultimate breaking capacity
32 A
4P 3d
Left
Toggle
By screws (plate)
Clip-on (DIN rail)
AC
50/60 Hz
16 kA 415 V AC
Icu 25 kA at 220...240 V AC 50/60 Hz conforming to IEC 60947-2
Icu 16 kA at 380...415 V AC 50/60 Hz conforming to IEC 60947-2
Icu 10 kA at 440 V AC 50/60 Hz conforming to IEC 60947-2
Icu 8 kA at 500 V AC 50/60 Hz conforming to IEC 60947-2
690 V AC 50/60 Hz conforming to IEC 60947-2
25 kA at 220...240 V AC 50/60 Hz conforming to IEC 60947-2
16 kA at 380...415 V AC 50/60 Hz conforming to IEC 60947-2
10 kA at 440 V AC 50/60 Hz conforming to IEC 60947-2
8 kA at 500 V AC 50/60 Hz conforming to IEC 60947-2
8 kV conforming to IEC 60947-2
800 V conforming to IEC 60947-2
Thermal-magnetic
TM-D
1
[Ue] rated operational voltage
[Ics] rated service breaking capacity
[Uimp] rated impulse withstand voltage
[Ui] rated insulation voltage
Trip unit technology
Trip unit name
Aug 17, 2019
Disclaimer: This documentation is not intended as a substitute for and is not to be used for determining suitability or reliability of these products for specific user applications
Trip unit protection functions
Trip unit rating
Protection type
Long time pick-up adjustment range
Short-time pick-up adjustment type Isd
Short-time delay adjustment type
Magnetic hold current
Magnetic tripping current
Suitability for isolation
Utilisation category
9 mm pitches
Connection pitch
Connections - terminals
Tightening torque
Local signalling
Number of slots
LI
32 A at 40 °C
Overload protection (thermal)
Short-circuit protection (magnetic)
0.7...1 x In
Fixed
Fixed
480 A
720 A
Yes conforming to IEC 60947-2
Category A
12 module
35 mm with spreaders
27 mm without spreaders
1 Everlink lug wire size 2.5…95 mm², rigid or stranded aluminium/copper
1 Everlink lug wire size 2.5…70 mm², flexible copper
5 N.m for 2.5…10 mm²
9 N.m for 16…95 mm²
Presence of auxiliary contacts: flag (green)
1 slot(s) for auxiliary switch OF
1 slot(s) for alarm switch SD
1 slot(s) for voltage release MN or MX
20 mm
Power wire stripping length
Environment
Quality labels
Standards
Product certifications
CE
EN/IEC 60947
CCC
EAC
Marine
Grey (RAL 7016)
Front cover: IP40 conforming to IEC 60529
IK07 conforming to IEC 62262
3 conforming to IEC 60947-1
-25…70 °C
-40…85 °C
2000 m without derating
5000 m with derating
20000 cycles conforming to IEC 947-1 Annex K ed 5.2 In
10000 cycles conforming to IEC 947-1 Annex F ed 5.2 for In at 440 V
137 mm
108 mm
80 mm
1.42 kg
Set of 1
Colour
IP degree of protection
IK degree of protection
Pollution degree
Ambient air temperature for operation
Ambient air temperature for storage
Operating altitude
Mechanical durability
Electrical durability
Height
Width
Depth
Net weight
Quantity per set
Offer Sustainability
Sustainable offer status
REACh Regulation
EU RoHS Directive
Mercury free
RoHS exemption information
China RoHS Regulation
Green Premium product
REACh Declaration
Pro-active compliance (Product out of EU RoHS legal scope)
EU RoHS Declaration
Yes
Yes
Download RoHS China Declaration
Product out of China RoHS scope. Substance declaration for your information
2
Environmental Disclosure
Circularity Profile
WEEE
Product Environmental Profile
No need of specific recycling operations
The product must be disposed on European Union markets following specific waste collection and
never end up in rubbish bins
Contractual warranty
Warranty
18 months
