Product catalogue | PCB connection systems | PCB plug-in connectors | Pitch 7.62 mm (0.300 inch) - SV/BV | Socket
connectors, tension clamp connection, pitch 7.62 | BVZ 7.62HP 180 | BVZ 7.62HP 180SH210 SN
General ordering data
Order No.
Part designation
Version
EAN
Qty.
System parameters
Conductor connection system
Outgoing direction of conductor
Pitch
Pitch in inch
No. of poles
No. of rows
Screwdriver blade
Screwdriver blade standard
Tightening torque, min.
Tightening torque, max.
Clamping screw
Stripping length
L1 in mm
L1 in inch
Electric shock protection to DIN VDE 0470
Electric shock protection to DIN VDE 0470
Material data
Insulating material
Colour
colour chart
Insulating material group
Flammability class UL 94
CTI
Contact base material
1933460000
BVZ 7.62HP/06SH210 SN SW
PCB plug-in connector, Female connectors,
Clamping yoke connection, Clamping range, max.:
6 mm², Pitch: 7.62 mm, No. of poles: 6, 180°, Box
4032248585847
25 pc(s).
Clamping yoke connection
180°
7.62 mm
0.3 inch
6
1
0.6 x 3.5
DIN 5264
0.5 Nm
0.6 Nm
M 2.5
12 mm
38.1 mm
1.5 inch
IP 20
Safe from finger touch
PA GF
black
Similar to RAL 9011
I
V-0
>= 600
Copper alloy
-1-
Product catalogue | PCB connection systems | PCB plug-in connectors | Pitch 7.62 mm (0.300 inch) - SV/BV | Socket
connectors, tension clamp connection, pitch 7.62 | BVZ 7.62HP 180 | BVZ 7.62HP 180SH210 SN
Material data
Contact surface
Connectable conductors
Clamping range, min.
Clamping range, max.
AWG, min.
AWG, max.
Solid, min. H05(07) V-U
Solid, max. H05(07) V-U
Flexible, min. H05(07) V-K
Flexible, max. H05(07) V-K
With wire end ferrule, acc. to DIN 46 228/1, min.
With wire end ferrule, acc. to DIN 46 228/1, max.
w. plastic collar ferrule, DIN 46228 pt 4, min.
w. plastic collar ferrule, DIN 46228 pt 4, max.
Gauge to EN 60999 a x b; ø
DIN IEC rating data
Rated current, min. No. pins (Tu=20°C)
Rated current, min. No. pins(Tu=40°C)
Rated voltage for overvoltage class/pollution
severity II/2
Rated voltage for overvoltage class/pollution
severity III/2
Rated voltage for overvoltage class/pollution
severity III/3
Rated impulse withstand voltage for overvoltage
class/pollution severity II/2
Rated impulse withstand voltage for overvoltage
class/pollution severity III/2
Rated impulse withstand voltage for overvoltage
class/pollution severity III/3
CSA rating data
Rated voltage (Use group C)
Rated current (Use group C)
AWG conductor (field wiring), min.
AWG conductor (field wiring), max.
UL 1059 rating data
Rated voltage (Use group C)
Rated current (Use group C)
AWG conductor, min.
AWG conductor, max.
tinned
0.2 mm²
6 mm²
22
10
0.2 mm²
6 mm²
0.5 mm²
6 mm²
0.25 mm²
6 mm²
0.25 mm²
6 mm²
2.8 mm x 2.0 mm; 2.4 mm
41 A
41 A
1,000 V
1,000 V
800 V
6 kV
8 kV
8 kV
600 V
35 A
24
10
600 V
35 A
24
10
-2-
Product catalogue | PCB connection systems | PCB plug-in connectors | Pitch 7.62 mm (0.300 inch) - SV/BV | Socket
connectors, tension clamp connection, pitch 7.62 | BVZ 7.62HP 180 | BVZ 7.62HP 180SH210 SN
Approvals
Approvals institutes
Classifications
eClass 5.1
27-26-07-04
Similar products
Order No.
1933430000
1933440000
1933450000
Part designation
BVZ 7.62HP/03SH210 SN SW
BVZ 7.62HP/04SH210 SN SW
BVZ 7.62HP/05SH210 SN SW
Version
PCB plug-in connector, Female connectors, Clamping yoke
connection, Clamping range, max.: 6 mm², Pitch: 7.62 mm, No. of
poles: 3, 180°, Box
PCB plug-in connector, Female connectors, Clamping yoke
connection, Clamping range, max.: 6 mm², Pitch: 7.62 mm, No. of
poles: 4, 180°, Box
PCB plug-in connector, Female connectors, Clamping yoke
connection, Clamping range, max.: 6 mm², Pitch: 7.62 mm, No. of
poles: 5, 180°, Box
-3-
