WRAPOST RECEPTACLES
for 0,81 - 1,17 diameter pins
M
ON
S
I
CHI
A
PINS
NE
D
1052/1053
2,29
2,18
2,01
0,76
0,71 3,3
5,59
6,35
Basic Part
Number
# of
Wraps
Length
A
0383
2,31
2,92
2,31
1,68
22,10
3,18
1053-2
1052-3
2
3
9,14
13,08
5,08 5,21
6,35
Basic Part
Number
Board
Thickness
Length
V
0383-1
0383-2
0383-3
1,57
2,39
3,18
2,39
3,18
3,96
0,64
1,14
20,57
105X-X-17-XX-34-XX-02-0
Press-fit in 2,11 mounting hole
0383-X-17-XX-34-XX-02-0
Swage mount in 2,39 hole
0382
3,05
2,16
2,34
2,11
0,79
1,91 3,23
5,21
6,43
0,64
12,95
0382-3-17-XX-34-XX-02-0
Press-fit in 2,26 mounting hole
SPECIFICATIONS
SHELL MATERIAL:
Brass Alloy 360, 1/2 Hard
CONTACT MATERIAL:
Beryllium Copper Alloy 172, HT
PART MANUFACTURED IN
INCHES, METRIC FOR REF ONLY
TOLERANCES ON:
LENGTHS:
± 0,13
DIAMETERS: ± 0,05
ANGLES:
± 2°
ORDER CODE: XXXX - X - 17 - XX - 34 - XX - 02 - 0
BASIC PART #
SPECIFY SHELL FINISH:
01
5,08µm TIN/LEAD OVER NICKEL
80
5,08µm TIN OVER NICKEL
15
0,25µm GOLD OVER NICKEL
SPECIFY CONTACT FINISH:
01
5,08
µm
TIN/LEAD OVER NICKEL
80
5,08µm TIN OVER NICKEL
27
0,76µm GOLD OVER NICKEL
CONTACT
#34
CONTACT (DATA ON PAGE 212)
w w w. m i l l - m a x . c o m
165
516-922-6000
