MM74HC125, MM74HC126 — 3-STATE Quad Buffers
February 2008
MM74HC125, MM74HC126
3-STATE Quad Buffers
Features
■
Typical propagation delay: 13ns
■
Wide operating voltage range: 2V–6V
■
Low input current: 1µA maximum
■
Low quiescent current: 80µA maximum (74HC)
■
Fanout of 15 LS-TTL loads
General Description
The MM74HC125 and MM74HC126 are general pur-
pose 3-STATE high speed non-inverting buffers utilizing
advanced silicon-gate CMOS technology. They have
high drive current outputs which enable high speed oper-
ation even when driving large bus capacitances. These
circuits possess the low power dissipation of CMOS
circuitry, yet have speeds comparable to low power
Schottky TTL circuits. Both circuits are capable of driving
up to 15 low power Schottky inputs.
The MM74HC125 require the 3-STATE control input C to
be taken high to put the output into the high impedance
condition, whereas the MM74HC126 require the control
input to be low to put the output into high impedance.
All inputs are protected from damage due to static
discharge by diodes to V
CC
and ground.
Ordering Information
Order Number
MM74HC125M
MM74HC125SJ
MM74HC125MTC
MM74HC125N
MM74HC126M
MM74HC126SJ
MM74HC126MTC
MM74HC126N
Package
Number
M14A
M14D
MTC14
N14A
M14A
M14D
MTC14
N14A
Package Description
14-Lead Small Outline Integrated Circuit (SOIC), JEDEC MS-012, 0.150"
Narrow
14-Lead Small Outline Package (SOP), EIAJ TYPE II, 5.3mm Wide
14-Lead Thin Shrink Small Outline Package (TSSOP), JEDEC MO-153,
