Belden Plenum Compression Connector Cable Cross Reference Chart
RG59 PLENUM SIZE 1 CONNECTOR
Center Conductor:
Dielectric:
Outer Jacket:
.0317 ~ .0339
.147 ~ .157
.190 ~ .220
CABLE
Belden
8279
RG59 PLENUM SIZE 3 CONNECTOR
Center Conductor:
Dielectric:
Outer Jacket:
ProSNS
FS59BNCPL3
FS59RCAPL3
CABLE
Belden
82241
88241
General
C3500
.0210 ~ .0240
.130 ~ .137
.190 ~ .220
Double Bubble
DB59BNCPL3
DB59RCAPL3
INTELLIGENT TRANSPORTATION
SYSTEM (ITS) CONNECTOR
Center Conductor:
Dielectric:
Outer Jacket:
.024 ~ .034
.190 ~ .200
.295 ~ .305
Belden
8281
8281B
CABLE
West Penn
P806
ProSNS
Double Bubble
Liberty
RG59-CCTV-PL-
WHT
General
C5816
FS59BNCPL
FS59PL
FS59RCAPL
DB59BNCPL3
DB59RCAPL3
DB59BNCSL2-M
DB59BNCSL2-F
ProSNS
FS59PL, FS59BNCPL
FS59RCAPL
Double Bubble
DB59BNCSL2-M, DB59BNCSL2-F
RG59 PLENUM SIZE 2 CONNECTOR
Center Conductor:
Dielectric:
Outer Jacket:
ProSNS
FS59PL2
FS59BNCPL2
FS59RCAPL2
CABLE
Belden
82259, 543945
649948,
6439C8
1506A
ProSNS
West Penn
25819
Double Bubble
CABLE PRO
®
INSTALLATION TOOLS
ProSNS™
(FS Series Connectors)
CPLCCT-SLM
CPSNSCT-596
CPLCCT-LS59/11*
.0317 ~ .0339
.130 ~ .137
.190 ~ .220
Double Bubble
DB59PL2
DB59BNCPL2
DB59RCAPL2
DB59PL2/4
DB59BNCPL2/4
DB59RCAPL2/4
Coleman
99979
993236
Commscope
2020K-V
2036K-V
Genesis
5351
5355
Tappan
D30124
General
C3526
C8030
495023
495044
FS59BNCPL2
FS59PL2
FS59RCAPL2
DB59BNCPL2
DB59PL2
DB59RCAPL2
Double Bubble™
(DB Series Connectors)
PS59/6/RGB
CPLCRBC-BR
RG59 PLENUM SIZE 4 CONNECTOR
Center Conductor:
Dielectric:
Outer Jacket:
ProSNS
FS59PL4
FS59BNCPL4
FS59RCAPL4
CABLE
Belden
1506A
89108
643948, 649948
ProSNS
West Penn
25815
25819
25Q843
Double Bubble
.0317 ~ .0339
.134 ~ .141
.190 ~ .220
Double Bubble
DB59PL2/4
DB59BNCPL2/4
DB59RCAPL2/4
CSC
221125, 862732
221105, 861159
592002
Coleman
99969
993256
Tappan
D30009
D30124
H90224
General
495028
CABLE PRO
®
CABLE PREP TOOLS
PSA59/6
PS59/6/RGB
PSA59/6
FS59BNCPL4
FS59PL4
FS59RCAPL4
DB59BNCPL2/4
DB59PL2/4
DB59RCAPL2/4
RG59 SECURITY/CCTV CONNECTOR
Center Conductor:
Dielectric:
Outer Jacket:
ProSNS
FSNS59BNCSL
FS59RCASL
CABLE
Belden
1426A, 8212
8221, 9240
9265, 9659
5439W5, 543945
549945
ProSNS
West
Penn
804, 814
815, 819
AQC815
AQC819
2814
Double Bubble
.0317 ~ .0339
.137 ~ .148
.232 ~ .248
Double Bubble
DB59BNCSL
DB59RCASL
Coleman
92004, 92074
991055
991057
993251
993253
Commscope
5550, 5553
5554
2054V
Genesis
5001
5009
5013
5103
5104
Tappan
C30022
H90369
General
C1104, C1135
C1142
C8025
C8027
C8028
CPLCRBC-BR
CPSNSCT-596
FSNS59BNCSL
FS59RCASL
DB59BNCSL
DB59RCASL
RG6 PLENUM SIZE 2 CONNECTOR
Center Conductor:
Dielectric:
Outer Jacket:
ProSNS
FS6PL2
FS6BNCPL2
FS6RCAPL2
** = for DB connector series only
CABLE
Belden
1189AP, 82120
87120, 89120
89248,1530AP
9116P, 633938
633948, 639948
82248, 86120/633
ProSNS
Genesis
5352
5353
Double Bubble
CPLCCT-LS59/11
CPLCCT-SLM
.0339 ~ .0418
.165 ~ .172
.220 ~ .250
Double Bubble
DB6PL2
DB6BNCPL2
DB6RCAPL2
CSC
220400
862733
220402
862734
Coleman
921003, 921005
921007, 921009
921015, 921017
921019**
993265
Commscope
2275K-V
2277K-V
2279K-V
F660BVR
2227**
West Penn
25806
25841
25T841
256350
25Q841**
Tappan
D40012
D40018
D40045
H90061
H90794
General
C3521,
C3523
C3524,
C3525
C8031
495025
FS6BNCPL2
FS6PL2
FS6RCAPL2
DB6BNCPL2
DB6PL2
DB6RCAPL2
DBDS3BNC CONNECTOR
Center Conductor: .014 ~ .020
Dielectric:
.070 ~ .085
Outer Jacket:
.120 ~ .140
Double Bubble DBDS3BNC
CABLE
Belden
735A
DBDS4BNC CONNECTOR
Center Conductor:
Dielectric:
Outer Jacket:
.0317 ~ .0339
.145 ~ .155
.220 ~ .240
CABLE
Belden
734D1, 734D1T
DBDS4BNCPL CONNECTOR
Comm-
scope
734S1
CABLE
Belden
734A1P
Double Bubble
Comm-
scope
73501
Center Conductor:
Dielectric:
Outer Jacket:
.0317 ~ .0339
.145 ~ .155
.205 ~ .220
Comm-
scope
734CIP
DBDS3BNC
DBDS4BNC
8285 Tournament Drive, Memphis, TN 38125, USA
Customer Support: 800.685.9452 Fax: 901.748.4308
www.belden.com
Email: ccscustomerservice@belden.com
Double Bubble DBDS4BNC
Double Bubble DBDS4BNCPL
RG11 CONNECTOR
Center Conductor:
Dielectric:
Outer Jacket:
.0634 ~ .0647
.280 ~ .294
.339 ~ .355
Belden
613948, 6139B8
7732A, 89289, 9292
CABLE
CSC
220502
220500
ProSNS
West Penn
25811
25821
Coleman
821013
Tappan
D60001
D90011
716SNS1P11HPLA
ProSNS
716SNS1P11HPLA
Actual cable sizes may vary from manufacturer specifications, and testing may be required to verify proper connector fit
