DRAWING NO.
1
32-6001C-CUST
.223 ''
D
.194 ''
01
REVISIONS
ENGINEERING RELEASE
03-12-2013
T
T
T
T
L
M
.143 ''
.110 ''
.120 ''
Description:
B-Wire Connector; Splices 17 AWG
bare wire and 22 AWG Insulated wire
D
Part No:
Material:
32-6001C
Insulation-PVC
Outer shell-Soft Metal Alloy
Piercing Teeth- Plated Phosphor-bronze
C
.772 ''
C
.630 ''
B
25.5mm
B
PVC TUBING
CUSTOMER COPY
A
CONNECTION INSERT
TOLERANCE UNLESS DRAWN BY
OTHERWISE SPECIFIED
TONY. T
DATE
03-12-13
DATE
OUTER SHELL
DECIMALS
X
X.X
X.XX
ANGLES
mm
CHECKED BY
Connectivity
Solutions
TITLE
A
+
0.5
-
+
0.3
-
+
0.1
-
+
0.5
v
-
TONY. T
LIN. M
U/M
mm
03-12-13
03-12-13
APPROVED BY DATE
B-Wire Connector; Splices 17 AWG
bare wire and 22 AWG Insulated wire
SHEET
1 OF 1
DRAWING NO.
SIZE
THIS DRAWING WAS PRODUCED BY COMPUTER,
DO NOT SCALE DRAWING OR UPDATE MANUALLY.
32-6001C-CUST
A
5
4
3
2
1
Mouser Electronics
Authorized Distributor
Click to View Pricing, Inventory, Delivery & Lifecycle Information:
Emerson Connectivity Solutions
:
32-6001C
