CY7C1161V18
CY7C1176V18
CY7C1163V18
CY7C1165V18
18-Mbit QDR™-II+ SRAM 4-Word Burst
Architecture (2.5 Cycle Read Latency)
Features
■
Functional Description
The CY7C1161V18, CY7C1176V18, CY7C1163V18, and
CY7C1165V18 are 1.8V Synchronous Pipelined SRAMs
equipped with QDR™-II+ architecture. QDR-II+ architecture
consists of two separate ports to access the memory array. The
read port has dedicated data outputs to support read operations
and the write port has dedicated data inputs to support write
operations. QDR-II+ architecture has separate data inputs and
data outputs to completely eliminate the need to turn around the
data bus that is required with common IO devices. Each port can
be accessed through a common address bus. Addresses for
read and write addresses are latched onto alternate rising edges
of the input (K) clock. Accesses to the QDR-II+ read and write
ports are completely independent of one another. In order to
maximize data throughput, both read and write ports are
equipped with Double Data Rate (DDR) interfaces. Each
address location is associated with four 8-bit words
(CY7C1161V18), 9-bit words (CY7C1176V18), 18-bit words
(CY7C1163V18), or 36-bit words (CY7C1165V18) that burst
sequentially into or out of the device. Because data can be trans-
ferred into and out of the device on every rising edge of both input
clocks K and K, memory bandwidth is maximized while simpli-
fying system design by eliminating bus turnarounds.
Depth expansion is accomplished with port selects for each port.
Port selects allow each port to operate independently.
All synchronous inputs pass through input registers controlled by
the K or K input clocks. All data outputs pass through output
registers controlled by the or K or K input clocks. Writes are
conducted with on-chip synchronous self-timed write circuitry.
Separate independent read and write data ports
❐
Supports concurrent transactions
300 MHz to 400 MHz clock for high bandwidth
4-word burst to reduce address bus frequency
Double Data Rate (DDR) interfaces on both read and write ports
(data transferred at 800 MHz) at 400 MHz
Read latency of 2.5 clock cycles
Two input clocks (K and K) for precise DDR timing
❐
SRAM uses rising edges only
Echo clocks (CQ and CQ) simplify data capture in high speed
systems
Single multiplexed address input bus latches address inputs
for both read and write ports
Separate port selects for depth expansion
Data valid pin (QVLD) to indicate valid data on the output
Synchronous internally self-timed writes
Available in x8, x9, x18, and x36 configurations
Full data coherency providing most current data
Core V
DD
= 1.8V ± 0.1V; IO V
DDQ
= 1.4V to V
DD[1]
Available in 165-ball FBGA package (13 x 15 x 1.4 mm)
Offered in both Pb-free and non Pb-free packages
Variable drive HSTL output buffers
JTAG 1149.1 compatible test access port
Delay Lock Loop (DLL) for accurate data placement
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
Configurations
With cycle read latency of 2.5 cycles:
CY7C1161V18 – 2M x 8
CY7C1176V18 – 2M x 9
CY7C1163V18 – 1M x 18
CY7C1165V18 – 512K x 36
Selection Guide
400 MHz
Maximum Operating Frequency
Maximum Operating Current
400
1080
375 MHz
375
1020
333 MHz
333
920
300 MHz
300
850
Unit
MHz
mA
Note
1. The QDR consortium specification for V
DDQ
is 1.5V + 0.1V. The Cypress QDR devices exceed the QDR consortium specification and are capable of supporting V
DDQ
= 1.4V to V
DD
.
Cypress Semiconductor Corporation
Document Number: 001-06582 Rev. *C
•
198 Champion Court
•
San Jose
,
CA 95134-1709
•
408-943-2600
Revised June 15, 2007
