ILLUMINATED PUSHBUTTON SWITCHES & MATCHING PANEL MOUNT INDICATORS
183 SERIES INDICATOR LIGHTS
PART NO.
CAP
FIG
1
2
183-9730-14-602 ALL
183-9830-14-604 ALL
13.94
[.549]
21.42
[.84]
MAX
10.31
[.41]
Caps Ordered Separately, See Below
21.42
[.84]
MAX
12.29
[.48]
Uses:
T-1 3/4 MIDGET
FLANGE BASE
INCANDESCENT LAMP
11.84 [.469] -
32NS - 2A THD.
FRONT PANEL MOUNT
12.70 [.500] - 32 NS
KNURLED FLANGE NUT
2A THD.
2.39 [.094] X 16.51 [.650]
MAX O.D.
FRONT OR REAR PANEL MOUNT
Fig. 1
Fig. 2
184, 186, 187, 188, 302, 304, 305 & 307 SERIES CAPS
1/2" SQUARE
CAP PART NO.
184-1871
184-1872
184-1873
184-1875
1/2" ROUND
COLOR
RED
GREEN
YELLOW
WHITE
11.13
[.438]
FIG
3
3
3
3
CAP PART NO.
186-1471
186-1472
186-1473
186-1475
COLOR
RED
GREEN
YELLOW
WHITE
FIG
7
7
7
7
ANTI-
ROTATION
TAB
12.70
[.500]
SQ.
11.13
[.438]
15.77
[.621]
SQ.
ANTI-
ROTATION
TAB
Fig. 3
11.13
[.438]
19.05
[.750]
SQ.
1.96
[.078]
11.13
[.438]
Fig. 4
18.95
[.746]
SQ.
5/8" SQUARE
†
CAP PART NO.
304-1871
304-1872
304-1873
304-1875
5/8" ROUND
†
COLOR
RED
GREEN
YELLOW
WHITE
FIG
4
4
4
4
CAP PART NO.
305-1471
305-1472
305-1473
305-1475
COLOR
RED
GREEN
YELLOW
WHITE
FIG
8
8
8
8
Fig. 5
11.13
[.438]
1.96
[.078]
3/4" SQUARE
CAP PART NO.
187-1871
187-1872
187-1873
187-1875
3/4" ROUND
COLOR
RED
GREEN
YELLOW
WHITE
Fig. 6
11.13
[.438]
15.77
[.621]
SQ.
FIG
5
5
5
5
CAP PART NO.
188-1471
188-1472
188-1473
188-1475
COLOR
RED
GREEN
YELLOW
WHITE
FIG
9
9
9
9
12.70
[.500]
SQ.
1.96
[.078]
3/4" SQUARE
†
CAP PART NO.
307-1871
307-1872
307-1873
307-1875
3/4" x 1" RECTANGULAR
†
COLOR
RED
GREEN
YELLOW
WHITE
Fig. 7
Fig. 8
19.05
[.750]
SQ.
11.13
[.438]
18.54
[.730]
FIG
6
6
6
6
CAP PART NO.
302-3471
302-3472
302-3473
302-3475
COLOR
RED
GREEN
YELLOW
WHITE
FIG
10
10
10
10
11.13
[.438]
24.64
[.970]
1.96
[.078]
Please contact factory for legend information available on Figures 3 thru 10
Fig. 9
Fig. 10
534 SERIES CAP KITS
3/4" x 1" LEGEND KITS†
KIT PART NO.
534-0701-030
534-0701-037
534-0701-537
LENS/FILTER COLOR
RED, GREEN, AMBER, BLUE/NONE
CLEAR/NONE
CLEAR/RED, GREEN, AMBER, BLUE
FIG
11
11
11
CAP BASE
UNDERLYING
FILTER
DIFFUSING
LENS
LEGEND
PLATE
LENS
BLACK
FRAME
11.13
[.438]
18.54
[.730]
13.97
[.550]
20.07
[.790]
24.64
[.970]
Legends provided by Dialight Stocking Distributors
† Feature fingertip grip for use with snap-in mount switches and indicators
Material & Finish: Base, Clear anodized aluminum;
Cap, High temperature scratch-resistant plastic
Neon and incandescent lamp information on Pages 35 and 36.
Dimensions in mm [inches]
1.96
[.078]
Fig. 11
534-0701-537 SHOWN
