1-1546640-1 Product Details
Live Product Chat
Terminal Block Connectors
Not re vie we d for R oHS C om plia nce
No Im a ge Ava ila ble
Quick Links
C heck Pricing & Availability
Search for Tooling
View Mating Products (2)
Product Feature Selector
C ontact Us About This Product
1-1546640-1
T E I nternal N umber: 1 - 1 5 4 6 6 4 0 - 1
Product Highlights:
l
C onnector
l
C onnector Type = Header
l
Not Shrouded
l
Housing C olor = Black
l
Not Side Stackable
View all Features
Obsolete
C ontact Product Information
C enter
A dd to M y P art L is t
Reques t Sample
Find Similar P roduc ts
Buy P roduc t
Documentation & Additional Information
Product Drawings:
l
None Available
Catalog Pages/Data Sheets:
l
None Available
Product Specifications:
l
None Available
Application Specifications:
l
None Available
Instruction Sheets:
l
None Available
CAD Files:
l
None Available
Additional Information:
l
Product Line Information
Related Products:
l
Tooling
l
Mating Products (2)
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
l
Product Type
= C onnector
l
C onnector Type
= Header
l
Shrouded
= No
l
Number of Positions
= 11
l
Mount Angle
= Vertical
Electrical Characteristics:
l
C urrent Rating, Max. (Amps.) = 12
l
Voltage (VAC ) = 300
Body Related Features:
l
Side Stackable
= No
l
Number of Rows
= Single
l
C enterline (mm [in])
= 5.00 [0.197]
l
C losed End
= Without
l
Flammability Rating = UL 94V-0
l
PC B Tail Length (mm [in]) = 3.50 [0.138]
l
Pin Length (mm [in]) = 10.00 [0.394]
Contact Related Features:
l
Threaded Flange
= Without
l
Screw Flange
= Without
l
C ontact Base Material = Brass
l
C ontact Mating Area Plating Material = Tin
Housing Related Features:
l
Housing C olor
= Black
l
Housing Material = Polyamide 6.6
Industry Standards:
l
RoHS/ELV C ompliance
= Not reviewed for ELV/RoHS compliance
l
Lead Free Solder Processes
= Not reviewed for lead free solder
process
Other:
l
Brand = Tyco Electronics
