INIATURE
M
INIATURE
F
USES
WICKMANN
5x20mm / No. 194
250V,
IEC 60127-2/I, 250V, F
Time-Current Characteristic
Quick Acting (F)
Specifications
Packaging
000:
002:
040:
043:
Bulk (1000 pcs.)
Bulk (10 pcs.)
Axial Leads - Bulk (1000 pcs.)
Axial Leads - Tape/Reel (1250 pcs.)
Ceramic
Nickel-plated brass
Silver-plated caps
Tin-plated copper wires
Standard
IEC 60127-2/I
DIN 41660
Approvals
VDE: License No. 115270/97123
SEMKO: Certificate No. 9841086
cULus Recognized: File No. E 67006
Materials
Tube:
End Caps:
Axial Leads:
Features
Dimensions (mm)
High breaking capacity
Direct solderable or plug-in versions
Internationally approved
Worldwide availability
Temperature
Operating Temperature
-25ºC to +70ºC (consider de-rating)
Climatic Category
-25ºC/+70ºC/21 days (EN 60068-1..3)
Stock Conditions
+10ºC to +60ºC
relative humidity
≤
75% yearly average,
without dew, maximum value for 30 days-95%
∅
5,2
20
0,65
+0.04
-0.01
∅
5,4
21 +0,5
103,5 max.
WebLinks
Data Sheet
www.wickmann.com/products/194.pdf
Approval Certificates
www.wickmann.com/approvals
Vibration Resistance
24 cycles at 15 min. each (EN 60068-6)
10 - 60Hz at 0.75mm amplitude
60 - 2000Hz at 10g acceleration
Time-Current Curve
www.wickmann.com/itcurves
Solderability
260ºC,
≤
3 sec. (Wave)
350ºC,
≤
1 sec. (Hand)
Packaging
www.wickmann.com/pack
FaxBack Document # 203
Soldering Heat Resistance
260ºC, 10 sec. (IEC 60068-2-20)
Marking
Limits for Pre-arcing Time
Rated Current
200mA ... 3.15A
4.00A ... 6.30A
8.00A ... 10.00A
, F, Current Rating, H, 250V, Approvals
1.5 x I
Rated
> 1h
> 1h
> 30min
2.1 x I
Rated
< 30 min
< 30 min
< 30 min
2.75 x I
Rated
4 x I
Rated
10 x I
Rated
<20ms
<20ms
<20ms
Unit Weight
1.2g (approx.)
2.2g (with leads)
10ms ... 2s 3ms ... 300ms
10ms ... 3s 3ms ... 300ms
10ms ... 3s 3ms ... 300ms
SEMKO
200mA
1
250mA
315mA
1
400mA
1
500mA
1
630mA
1
800mA
1
1.00A
1.25A
1.60A
2.00A
2.50A
3.15A
4.00A
5.00A
6.30A
2
8.00A
10.00A
1,2
1
0200
0250
0315
0400
0500
0630
0800
1100
1125
1160
1200
1250
1315
1400
1500
1630
1800
2100
250V
250V
250V
250V
250V
250V
250V
250V
250V
250V
250V
250V
250V
250V
250V
250V
250V
250V
1500A / 250VAC
50-60Hz
cos
ϕ
= 0.7-0.8
3500
1000
950
900
850
800
750
700
650
500
400
350
300
270
250
200
180
170
1.2
0.8
0.8
0.9
1.0
1.1
1.3
1.4
1.6
1.8
2.0
2.3
2.8
3.5
3.7
4.0
3.0
4.0
0.007
0.013
0.015
0.027
0.041
0.075
0.12
0.29
0.7
1.0
1.8
3.0
7.8
15
35
75
130
150
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
1 Axial leads not available below 1A or above 8A.
2 Not mentioned in the fuse standards.
Order
Information
010215
Qty.
Order-
Number
Series
194
Amp Code
Packaging
WebSite:
www.wickmann.com
FaxBack: +1 (404) 699-6176
• Europe
Tel: +49 (2302) 662-107
• Americas
Tel: +1 (404) 699-7820
• Asia
Tel: +852 26 14-1108
E-mail: sales@wickmann.com
E-mail: service@wickmannusa.com E-mail: sales@wickmann.com.hk
cURus
VDE
100%
Permissible continuous operating current is
≤
100% at ambient temperature of 23ºC (73.4ºF).
Rated
Amp
Voltage
Breaking
Voltage Drop Power Dissipation Melting Integral
Current
Code
Rating
Capacity
1.0 x I
Rated
1.5 x I
Rated
10 x I
Rated
max. (mV)
max. (W)
max. (A
2
s)
Approvals
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
