1N3314BLEADFREE datasheet, PDF

Datasheet> All Categories > Discrete semiconductor> diode> 1N3314BLEADFREE

1N3314BLEADFREE: DescriptionZener Diode, 15V V(Z), 5%, 50W, Silicon, Unidirectional, DO-5, HERMETICALLY SEALED, METAL PACKAGE-1; CategoryDiscrete semiconductor diode; File Size353KB，2 Pages; ManufacturerCentral Semiconductor; Environmental Compliance

Download Datasheet Parametric View All

1N3314BLEADFREE Overview

Zener Diode, 15V V(Z), 5%, 50W, Silicon, Unidirectional, DO-5, HERMETICALLY SEALED, METAL PACKAGE-1

1N3314BLEADFREE Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	Central Semiconductor
Parts packaging code	DO-5
package instruction	O-MUPM-D1
Contacts	1
Reach Compliance Code	compliant
ECCN code	EAR99
Is Samacsys	N
Other features	HIGH RELIABILITY
Shell connection	CATHODE
Configuration	SINGLE
Diode component materials	SILICON
Diode type	ZENER DIODE
Maximum dynamic impedance	80 Ω
JEDEC-95 code	DO-5
JESD-30 code	O-MUPM-D1
JESD-609 code	e3
Number of components	1
Number of terminals	1
Maximum operating temperature	175 °C
Package body material	METAL
Package shape	ROUND
Package form	POST/STUD MOUNT
Peak Reflow Temperature (Celsius)	260
polarity	UNIDIRECTIONAL
Maximum power dissipation	50 W
Certification status	Not Qualified
Nominal reference voltage	15 V
surface mount	NO
technology	ZENER
Terminal surface	MATTE TIN (315)
Terminal form	SOLDER LUG
Terminal location	UPPER
Maximum time at peak reflow temperature	10
Maximum voltage tolerance	5%
Working test current	830 mA
Base Number Matches	1

Preview

Download Datasheet

View All

1N3305B THRU 1N3350B

SILICON ZENER DIODES

6.8 VOLT THRU 200 VOLT

50W, 5% TOLERANCE

w w w. c e n t r a l s e m i . c o m

DESCRIPTION:

The CENTRAL SEMICONDUCTOR 1N3305B series

types are silicon Zener diodes manufactured in a

hermetically sealed metal case, designed for high

reliability industrial applications. Also available in

reverse polarity connection (replace “B” suffix with “RB”

suffix in part number - ex. 1N3305RB).

MARKING: FULL PART NUMBER

DO-5 CASE

MAXIMUM RATINGS:

(TC=75°C)

Power Dissipation

Operating and Storage Junction Temperature

Thermal Resistance

SYMBOL

TJ, Tstg

UNITS

°C

°C/W

-65 to +175

2.0

ELECTRICAL CHARACTERISTICS:

(TC=30°C unless otherwise noted) VF=1.5V MAX @ IF=10A

ZENERVOLTAGE

TYPE

MIN

1N3305B

1N3306B

1N3307B

1N3308B

1N3309B

1N3310B

1N3311B

1N3312B

1N3313B

1N3314B

1N3315B

1N3316B

1N3317B

1N3318B

1N3319B

1N3320B

1N3321B

1N3322B

1N3323B

1N3324B

1N3325B

1N3326B

1N3327B

1N3328B

1N3329B

1N3330B

6.460

7.125

7.790

8.645

9.500

10.45

11.40

12.35

13.30

14.25

15.20

16.15

17.10

18.05

19.00

20.90

22.80

23.75

25.65

28.50

31.35

34.20

37.05

40.85

42.75

44.65

VZ @ IZT

NOM

6.8

7.5

8.2

9.1

MAX

7.140

7.875

8.610

9.555

10.50

11.55

12.60

13.65

14.70

15.75

16.80

17.85

18.90

19.95

21.00

23.10

25.20

26.25

28.35

31.50

34.65

37.80

40.95

45.15

47.25

49.35

TEST

CURRENT

IZT

1850

1700

1500

1370

1200

1100

1000

960

890

830

780

740

700

660

630

570

520

500

460

420

380

350

320

290

280

270

MAXIMUM ZENER

IMPEDANCE

ZZT @ IZT

0.2

0.3

0.4

0.5

0.6

0.8

1.0

1.1

1.2

1.4

1.6

1.8

2.0

2.2

2.4

2.5

2.6

2.7

2.8

3.0

3.2

3.5

4.0

4.5

5.0

ZZK @ IZK

100

5.0

MAXIMUM

REVERSE

CURRENT

@ VR

μA

150

5.0

4.5

5.0

5.4

6.1

6.7

8.4

9.1

9.9

10.6

11.4

12.2

13.0

13.7

14.4

15.2

16.7

18.2

19.0

20.6

22.8

25.1

27.4

29.7

32.7

34.2

35.8

MAXIMUM

ZENER

CURRENT

(TC=75°C MAX)

IZM

6600

5900

5200

4800

4300

3900

3600

3300

3000

2800

2650

2500

2300

2200

2100

1900

1750

1550

1500

1400

1300

1150

1050

975

930

880

TYPICAL

TEMPERATURE

COEFFICIENT

V

%/°C

0.040

0.045

0.048

0.051

0.055

0.060

0.065

0.070

0.075

0.080

0.085

0.090
