1N5819+

Description
Rectifier Diode,
CategoryDiscrete semiconductor    diode
File Size392KB,3 Pages
ManufacturerSPC Multicomp
Download Datasheet Parametric View All

1N5819+ Overview

Rectifier Diode,

1N5819+ Parametric

Parameter NameAttribute value
MakerSPC Multicomp
package instructionO-PALF-W2
Reach Compliance Codeunknown
Is SamacsysN
Other featuresHIGH RELIABILITY
Shell connectionISOLATED
ConfigurationSINGLE
Diode component materialsSILICON
Diode typeRECTIFIER DIODE
JEDEC-95 codeDO-41
JESD-30 codeO-PALF-W2
Number of components1
Number of terminals2
Maximum operating temperature125 °C
Minimum operating temperature-65 °C
Maximum output current1 A
Package body materialPLASTIC/EPOXY
Package shapeROUND
Package formLONG FORM
Maximum repetitive peak reverse voltage40 V
surface mountNO
technologySCHOTTKY
Terminal formWIRE
Terminal locationAXIAL
Base Number Matches1
Schottky Rectifier
Features
Low forward voltage drop
High current capability
High reliability
High surge current capability
Mechanical Data:
Cases
Lead
Polarity
High Temperature
Soldering Guaranteed
: Moulded plastic DO-41
: Axial leads, solderable per MIL-STD-202, Method 208 guaranteed
: Colour band denotes cathode end
: 260°C / 10 seconds / 0.375 inches (9.5mm) lead
lengths at 5 lbs., (2.3 kg) tension
Maximum Ratings and Electrical Characteristics
Rating at 25°C ambient temperature unless otherwise specified.
Single phase, half wave, 60 Hz, resistive or inductive load.
For capacitive load, derate current by 20%
Parameter
Maximum Repetitive Peak Reverse Voltage
Maximum RMS Voltage
Maximum DC Blocking Voltage
Maximum Average Forward Rectified Current
0.375 Inches (9.5 mm) Lead Length at T
l
= 90°C
Peak Forward Surge Current, 8.3 ms Single Half Sine-wave
Superimposed on Rated Load (JEDEC method)
Maximum Instantaneous Forward Voltage at 1A
Maximum Instantaneous Forward Voltage at 3A
Maximum DC Reverse Current at T
a
= 25°C
at Rated DC Blocking Voltage at T
a
= 100°C
Typical Thermal Resistance (Note 1)
Typical Junction Capacitance (Note 2)
Operating Temperature Range
Storage Temperature Range
Notes:
1. Mount on Cu-Pad Size 5 × 5 mm on PCB
2. Measured at 1 MHz and applied reverse voltage of 4V DC
Symbol
V
rrm
V
rms
V
dc
I
(AV)
I
fsm
V
f
I
r
R
θJA
R
θJC
C
j
T
j
T
stg
0.45
0.75
1N5817+ 1N5818+ 1N5819+
20
14
20
30
21
30
1
A
25
0.55
0.875
1
10
100
45
55
-65 to + 125
0.6
0.9
V
mA
°C/W
pF
°C
40
28
40
V
Unit
www.element14.com
www.farnell.com
www.newark.com
Page <1>
13/02/18
V1.1
