M Series Connectors
Product Facts
• Most connectors intermate-
able with connectors made
to MIL-C-28748 require-
ments
• Wide range of connector
styles and sizes: standard
connectors (unloaded),
posted connectors (pre-
loaded) and special applica-
tion connectors (unloaded)
• Complete line of accessory
hardware for fastening, pro-
tecting, guiding, shielding,
strain relief and keying
• A variety of contacts:
signal, power, coaxial and
posted versions - many are
interchangeable and can be
intermixed in the same con-
nector housing
• Full complement of applica-
tion tooling for wire crimp
and posted terminations -
hand tools, semiautomatic
tooling and fully automatic
machines provide highly
reliable, low cost termina-
tions to meet production
requirements
Need More Information?
Call the Technical
Support Center:
1-800-522-6752.
The Center is staffed with
specialists well versed in all
AMP products and applica-
tion tooling. The Center can
provide you with:
•
Technical Support
•
Catalogs
•
Technical Documents
•
Product Samples
•
AMP FAX Service
Product Information Faxed
Immediately
•
Authorized Distributor
Locations
Specifications subject to change.
Consult Tyco Electronics Corporation for lat-
est design specifications.
©1968, 1970, 1972, 1974, 1978, 1985, 1990, 1996,
2001 and 2008 by Tyco Electronics Corpora-
tion. All Rights Reserved.
AMP, AMP FAX, AMPOMATOR,
AMP-O-LECTRIC, AMP-O-MATIC,
AMP-TAPETRONIC, CERTI-CRIMP, COAXICON,
LGH, POWERBAND,
PRO-CRIMPER, RAYCHEM,
TERMI-POINT and Tyco are trademarks.
Standard Housings
