5-175475-9 Product Details
Live Product Chat
Product Photo
1.27 [.050] Series I, HD, FH and J Connectors
5 of 6 EU R oHS/ELV C om plia nt
(
Find R oHS C om plia nt
Alte rna te s
/
Sta te m e nt of C om plia nce
)
Quick Links
C heck Pricing & Availability
Search for Tooling
Product Feature Selector
C ontact Us About This Product
5-175475-9
T E I nternal N umber: 5 - 1 7 5 4 7 5 - 9
Product Highlights:
l
C onnector
l
Receptacle
l
Number of Positions = 80
l
1.27 mm C enterline
l
Standard Profile
View all Features
Obsolete
C ontact Product Information C enter
View 3D PDF
A dd to M y P art L is t
Reques t Sample
Find Similar P roduc ts
Buy P roduc t
Documentation & Additional Information
Product Drawings:
l
None Available
Catalog Pages/Data Sheets:
l
C HAMP Interconnection System
(PDF, English)
l
REPRESENTATIVE TERMINALS AND C ONNEC TORS
(PDF, English)
l
C HAMP .050 SERIES C ONNEC TORS
(PDF, English)
Product Specifications:
l
C HAMP .050(I) Board-to-Board C onnector (1)
(PDF, English)
l
C HAMP .050(I) Board-to-Board C onnector (2)
(PDF, English)
Application Specifications:
l
None Available
Instruction Sheets:
l
None Available
CAD Files:
(C
AD Format & C ompression Information)
l
2D Drawing
(DXF, Version C )
l
3D Model
(IGES, Version C )
l
3D Model
(STEP, Version C )
List all Documents
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
l
Product Type
= C onnector
l
Gender
= Receptacle
l
Number of Positions
= 80
l
Profile
= Standard
l
PC B Mount Style = Through Hole
l
PC B Retention Feature = Yes
l
PC B Mount Angle
= Vertical
l
C onnector Type
= High Density (HD)
l
PC B Mount Polarization
= Without
l
Retention Leg Material = Brass
l
C olor = Black
l
Used For = Board To Board Applications
l
Sealed Bottom = Without
l
Product Series = Series I
Mechanical Attachment:
l
Retention Leg Plating = Tin-lead over Nickel
Termination Related Features:
l
Termination Post Length (mm [in])
= 3.10 [0.122]
Body Related Features:
l
C enterline (mm [in])
= 1.27 [0.050]
l
PC B Retention Method
= Boardlock(s)
Contact Related Features:
l
C ontact Mating Area Plating Material
= Gold (30)
l
C ontact Base Material = Phosphor Bronze
Housing Related Features:
l
Housing Temperature Rating
= Standard
l
Housing Material = Nylon
l
Housing Flammability Rating = UL 94V-0
Industry Standards:
l
RoHS/ELV C ompliance
= ELV compliant, 5 of 6 C ompliant
l
Lead Free Solder Processes
= Wave solder capable to 240?C
Operation/Application:
l
Application
= Standard
Other:
l
Brand = AMP
Additional Information:
l
Product Line Information
Related Products:
l
Tooling
