5-175487-5: DescriptionHEADER CONNECTOR,PCB MNT,RECEPT,15 CONTACTS,PIN,0.079 PITCH,PC TAIL W/RETNN TERMINAL,YELLOW; CategoryThe connector The connector; File Size103KB，1 Pages; ManufacturerTE Connectivity; Websitehttp://www.te.com

Download Datasheet Parametric View All

5-175487-5 Overview

HEADER CONNECTOR,PCB MNT,RECEPT,15 CONTACTS,PIN,0.079 PITCH,PC TAIL W/RETNN TERMINAL,YELLOW

5-175487-5 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
Maker	TE Connectivity
Reach Compliance Code	compliant
Is Samacsys	N
Other features	PACKAGING 500 PER BOX
body width	0.228 inch
subject depth	0.268 inch
body length	1.252 inch
Body/casing type	RECEPTACLE
Connector type	BOARD CONNECTOR
Contact to complete cooperation	SN-PB ON CU
Contact completed and terminated	TIN/LEAD OVER COPPER
Contact point gender	MALE
Contact material	BRASS
contact mode	RECTANGULAR
Contact resistance	20 mΩ
Contact style	RND PIN-SKT
Dielectric withstand voltage	1000VAC V
maximum insertion force	75.1712 N
Insulation resistance	500000000 Ω
Insulator color	YELLOW
insulator material	NYLON
Manufacturer's serial number	175487
Plug contact pitch	0.079 inch
Installation method	STRAIGHT
Installation type	BOARD
Number of connectors	ONE
PCB row number	1
Number of rows loaded	1
Maximum operating temperature	105 °C
Minimum operating temperature	-30 °C
PCB contact pattern	RECTANGULAR
Plating thickness	31u inch
polarization key	POLARIZED HOUSING
Rated current (signal)	2 A
Guideline	UL, CSA
reliability	COMMERCIAL
Terminal length	0.126 inch
Terminal pitch	2.0066 mm
Termination type	SOLDER KINKED LEADS
Total number of contacts	15
Evacuation force-minimum value	13.344 N
Base Number Matches	1

Preview

Download Datasheet

View All

C orporate Hom e

|

Electronic Components

|

Se gm e nts

|

W ho W e Are

My Account

Searc h

Products

Documentation

Resources

My Account

Customer Support

Home

>

Products

>

By Type

>

Discrete Wire C onnectors - IDC

>

Product Feature Selector

> Product Details

5-175487-5 Product Details

Live Product Chat

Product Photo

2mm AMP CT Connectors

Not EU R oHS or ELV C om plia nt

(

Find R oHS C om plia nt Alte rna te s

)

Quick Links

C heck Pricing & Availability

Search for Tooling

Product Feature Selector

C ontact Us About This Product

5-175487-5

T E I nternal N umber: 5 - 1 7 5 4 8 7 - 5

Product Highlights:

l

C onnector

l

C onnector Type = MT (Mass Termination)

l

Mating Type = Header

l

Number of Positions = 15

l

Number of Rows = 1

View all Features

Superseded

Search for Replacement Parts

A dd to M y P art L is t

Reques t Sample

Find Similar P roduc ts

Buy P roduc t

Documentation & Additional Information

Product Drawings:

l

POST HEADER ASS'Y (BOX-V TYPE) (AMP C T C ONNEC TOR 2mm...

(PDF, English)

Catalog Pages/Data Sheets:

l

None Available

Product Specifications:

l

AMP C ommon Termination (C T), C onn, 2mm Pitch, M/T Type

(PDF, English)

l

AMP C ommon Termination(C T), C onnector, 2mm Pitch, C r...

(PDF, English)

Application Specifications:

l

None Available

Instruction Sheets:

l

None Available

CAD Files:

l

None Available

List all Documents

Product Features

(Please use the Product Drawing for all design activity)

Product Type Features:

l

Product Type

= C onnector

l

C onnector Type

= MT (Mass Termination)

l

Mating Type

= Header

l

Number of Positions

= 15

l

PC B Mount Style

= Through Hole

l

PC B Mount Angle

= Vertical

l

PC B Mount Polarization

= No

l

PC B Retention Feature

= Yes

Mechanical Attachment:

l

Panel Attachment

= Without

Termination Related Features:

l

Solder Tail C ontact Plating = Pre-tinned

Body Related Features:

l

Number of Rows

= 1

l

Header Body Style

= Box

l

PC B Retention Method

= Retention Solder Tails

l

C enterline (mm [in]) = 2.00 [0.079]

Contact Related Features:

l

C ontact Base Material = Brass

l

C ontact Mating Area Plating Material = Pre-Tin

Housing Related Features:

l

Housing Material

= Nylon

l

Housing C olor

= Yellow

l

Housing Flammability Rating = UL 94V-0

Industry Standards:

l

RoHS/ELV C ompliance

= Not ELV/RoHS compliant

l

Lead Free Solder Processes

= Not suitable for lead free processing

Conditions for Usage:

l

Terminate To

= Printed C ircuit Board

Other:

l

Brand = AMP

Additional Information:

l

Product Line Information
