Low Cost, Low Jitter, Fast Delivery
lVPECl 7.5x5mm 3.3V VCXO
FXO-PC73 SERIES
RoHS Compliant / Free
Model: FVXO-PC73 SERIESRoHS Compliant / Pb Pb Free
Page 1 of 2
Rev. 9/6/2006 Preliminary
http://www.foxonline.com/need_a_sample.htm
1-888-XpressO
7.5 Max
Part Number
796-Frequency-xxxxx
MODEl SElECTION GuIDE
F VX O - P C 7 3 b R - 155.520000
P = LVPECL
C = Ceramic
7 = 7.5x5mm
3 = 3.3V
Frequency
Blank = -20~+70ºC
R = -40~+85ºC
B = ±50PPM APR
#6
X
#5
#4
PRESS
O
5.0 Max
#1
#2
#3
Pin 1 Designator
(FOX Head or Dot)
1.4 Max
2.54
1.4
#1
#6
#2
#5
5.08
#3
2.6
#4
• ElECTRICAl CHARACTERISTICS
Frequency Range (F
o
)
Absolute Pull Range (APR)
1
Storage Temperature Range (T
stg
)
Supply Voltage (V
dd
)
Control Voltage (V
c
)
Input Current
(I
dd
)
Output Symmetry (50% Vp-p Level)
Rise Time
(T
r
) (20% ~ 80% Vp-p)
Fall Time
(T
f
) (80% ~ 20% Vp-p)
Output Voltage (V
ol
)
(V
oh
)
Output Load
Start-up Time
(T
s
)
Output Enable / Disable Time
2
Linearity
Modulation Bandwidth
Maximum Soldering Temp / Time
Moisture Sensitivity Level (MSL)
Termination Finish
1
PARAMETERS
MAX
(unless otherwise noted)
1.000
MHz
~ 1.100
GHz
± 50 PPM Min
-55ºC ~ +125ºC
3.3V ± 5%
1.65V ± 1.5V
120mA
45% ~ 55%
400pS
400pS
1.305V ~ 1.65V
2.055V ~ 2.405V
50 Ohms
into V
dd
-2V
dc
t
yp
.
10mS
100nS
± 10%
10kHz Min
260ºC / 10 Seconds
1
Au
Recommended
Solder Pad Layout
2.54
2.54
2.0
4.2
1.8
All dimensions are in millimeters.
Actual Marking Depicted
Pin Connections
#1) Vc
#2) E/D
#3) GND
Recommended Circuit:
.01uF
Vc
#1
#6
V
DD
#4) Out 1
#5) Out 2
#6) V
dd
Inclusive of 25ºC tolerance, operating temperature range, input voltage change, load
change, aging, shock, and vibration.
2
An internal pullup resistor from pin 2 to pin 6 allows active output if pin 2 is left open.
- If you have specific jitter or phase noise requirements please contact Fox Technical
Support for availability.
- A 0.01µF bypass capacitor should be placed between
V
dd
(Pin 6) and GND
(Pin 3) to minimize power supply line noise.
- The above specifications, having been carefully prepared and checked, is believed
to be accurate at the time of publication; however, no responsibility is assumed by Fox
Electronics for inaccuracies.
E/D
#2
#5
#3
#4
50 Ohms
50 Ohms
.01uF
V
DD
- 2V
Patent Numbers:
US 6,664,860, US 5,960,403, US 5,952,890; US 5,960,405; US 6,188,290;
Foreign Patents: R.S.A. 98/0866, R.O.C. 120851; Singapore 67081, 67082; EP 0958652
China ZL 98802217.6, Malaysia MY-118540-A, Philippines 1-1998-000245
US and Foreign Patents Pending
X
PRESS
O® Fox Electronics
• ENAblE / DISAblE FuNCTION
2
OUTPUT (Pin 4, Pin 5)
(Pin 2)
ACTIVE
OPEN
'1' Level V
ih
≥
70%
V
dd
ACTIVE
'0' Level V
il
≤
30%
V
dd
V
ol
level
FOXElectronics
5570 Enterprise Parkway Fort Myers, Florida 33905 USA +1.239.693.0099 FAX +1.239.693.1554
http://www.foxonline.com
© 2006 FOX ELECTRONICS | ISO9001:2000 Certified
EMEA
Tel/Fax: +44 .1767.312632 |
Asia
Hong Kong Tel: +852.2854.4285 Fax +852.2854.4282 |
Taiwan
Tel: +886.2.22073427 Fax +886.2.22073486
|
Japan
Tel: +81.3.3374/2079 Fax: +81.3.3374.5221
lVPECl 7.5x5mm 3.3V VCXO
Model: FVXO-PC73 SERIES
Page 2 of 2
RoHS Compliant / Pb Free
Rev. 9/6/2006 Preliminary
http://www.foxonline.com/need_a_sample.htm
Low Cost, Low Jitter, Fast Delivery
1-888-XpressO
• TAPE SPECIFICATIONS
(millimeters)
MODEl
FVXO-PC73
• REEl SPECIFICATIONS
(millimeters)
G H
I
J
K
l M
b C D E
F
STD Reel QTY
MODEl
A
FVXO-PC73
2.0
∅13 ∅21 ∅80 ∅255
17.5 2.0
2,000
∅1.5
4.0 8.0 7.5 16.0 2.15
FOXElectronics
5570 Enterprise Parkway Fort Myers, Florida 33905 USA +1.239.693.0099 FAX +1.239.693.1554
http://www.foxonline.com
© 2006 FOX ELECTRONICS | ISO9001:2000 Certified
EMEA
Tel/Fax: +44 .1767.312632 |
Asia
Hong Kong Tel: +852.2854.4285 Fax +852.2854.4282 |
Taiwan
Tel: +886.2.22073427 Fax +886.2.22073486
|
Japan
Tel: +81.3.3374/2079 Fax: +81.3.3374.5221
