Product catalogue | PCB connection systems | PCB terminals | Clamping yoke connection | LL 5.00/5.08 multi-tier | LL3R
5.08/90
General ordering data
Order No.
Part designation
Version
EAN
Qty.
System parameters
Product family
Conductor connection system
Fitted to PCB
Outgoing direction of conductor
Pitch
Pitch in inch
No. of poles
Fitted by customer
Max. adjacent poles per row
No. of rows
Solder pin length
Dia. of fitting hole
Fitting hole tolerance
No. of solder pins per pole
Screwdriver blade
Screwdriver blade standard
Tightening torque, min.
Tightening torque, max.
Clamping screw
Stripping length
L1 in mm
L1 in inch
Electric shock protection to DIN VDE 0470
Electric shock protection to DIN VDE 0470
1979160000
LL3R 5.08/42/90 3.2 OR
PCB terminal, Clamping yoke connection,
Soldered connection, Clamping range, max.: 6
mm², Pitch: 5.08 mm, No. of poles: 42, 90°, Box
4032248674305
10 pc(s).
System LL
Clamping yoke connection
Soldered connection
90°
5.08 mm
0.2 inch
42
yes
24
3
3.2 mm
1.3 mm
+ 0.1 mm
1
0.6 x 3.5
DIN 5264
0.5 Nm
0.6 Nm
M3
6 mm
66.04 mm
2.6 inch
IP 20
Safe from finger touch
-1-
Product catalogue | PCB connection systems | PCB terminals | Clamping yoke connection | LL 5.00/5.08 multi-tier | LL3R
5.08/90
Material data
Insulating material
Colour
colour chart
Insulating material group
Flammability class UL 94
CTI
Contact base material
Contact surface
Storage temperature, min.
Storage temperature, max.
Connectable conductors
Clamping range, min.
Clamping range, max.
AWG, min.
AWG, max.
Solid, min. H05(07) V-U
Solid, max. H05(07) V-U
Flexible, min. H05(07) V-K
Flexible, max. H05(07) V-K
With wire end ferrule, acc. to DIN 46 228/1, min.
With wire end ferrule, acc. to DIN 46 228/1, max.
w. plastic collar ferrule, DIN 46228 pt 4, min.
w. plastic collar ferrule, DIN 46228 pt 4, max.
Gauge to EN 60999 a x b; ø
DIN IEC rating data
Rated voltage for overvoltage class/pollution
severity II/2
Rated voltage for overvoltage class/pollution
severity III/2
Rated voltage for overvoltage class/pollution
severity III/3
Rated impulse withstand voltage for overvoltage
class/pollution severity II/2
Rated impulse withstand voltage for overvoltage
class/pollution severity III/2
Rated impulse withstand voltage for overvoltage
class/pollution severity III/3
Short-time withstand current resistance
Wemid (PA)
orange
Similar to RAL 2000
I
V-0
>= 600
Copper alloy
tinned
-25 °C
55 °C
0.08 mm²
6 mm²
26
12
0.5 mm²
6 mm²
0.5 mm²
4 mm²
0.5 mm²
2.5 mm²
0.5 mm²
2.5 mm²
2.8 mm x 2.4 mm; 3.0 mm
630 V
320 V
250 V
4 kV
4 kV
4 kV
3 x 1s with 120 A
-2-
Product catalogue | PCB connection systems | PCB terminals | Clamping yoke connection | LL 5.00/5.08 multi-tier | LL3R
5.08/90
Approvals
Approvals institutes
Classifications
eClass 5.1
27-26-11-01
Similar products
Order No.
1979060000
1979080000
1979100000
1979120000
1979140000
1979180000
1979200000
1979220000
1979240000
1979260000
Part designation
LL3R 5.08/12/90 3.2 OR
LL3R 5.08/18/90 3.2 OR
LL3R 5.08/24/90 3.2 OR
LL3R 5.08/30/90 3.2 OR
LL3R 5.08/36/90 3.2 OR
LL3R 5.08/48/90 3.2 OR
LL3R 5.08/54/90 3.2 OR
LL3R 5.08/60/90 3.2 OR
LL3R 5.08/66/90 3.2 OR
LL3R 5.08/72/90 3.2 OR
Version
PCB terminal, Clamping yoke connection, Soldered connection,
Clamping range, max.: 6 mm², Pitch: 5.08 mm, No. of poles: 12, 90°,
Box
PCB terminal, Clamping yoke connection, Soldered connection,
Clamping range, max.: 6 mm², Pitch: 5.08 mm, No. of poles: 18, 90°,
Box
PCB terminal, Clamping yoke connection, Soldered connection,
Clamping range, max.: 6 mm², Pitch: 5.08 mm, No. of poles: 24, 90°,
Box
PCB terminal, Clamping yoke connection, Soldered connection,
Clamping range, max.: 6 mm², Pitch: 5.08 mm, No. of poles: 30, 90°,
Box
PCB terminal, Clamping yoke connection, Soldered connection,
Clamping range, max.: 6 mm², Pitch: 5.08 mm, No. of poles: 36, 90°,
Box
PCB terminal, Clamping yoke connection, Soldered connection,
Clamping range, max.: 6 mm², Pitch: 5.08 mm, No. of poles: 48, 90°,
Box
PCB terminal, Clamping yoke connection, Soldered connection,
Clamping range, max.: 6 mm², Pitch: 5.08 mm, No. of poles: 54, 90°,
Box
PCB terminal, Clamping yoke connection, Soldered connection,
Clamping range, max.: 6 mm², Pitch: 5.08 mm, No. of poles: 60, 90°,
Box
PCB terminal, Clamping yoke connection, Soldered connection,
Clamping range, max.: 6 mm², Pitch: 5.08 mm, No. of poles: 66, 90°,
Box
PCB terminal, Clamping yoke connection, Soldered connection,
Clamping range, max.: 6 mm², Pitch: 5.08 mm, No. of poles: 72, 90°,
Box
-3-
