SVFL2800S Series
HIGH RELIABILITY HYBRID
RADIATION TOLERANT DC-DC CONVERTERS
DESCRIPTION
The SVFL series of high reliability DC-DC converters is
operable over the full military temperature range (-55 °C to
+125 °C) with no power derating. Paramount to the SVFL
series is a magnetic feedback circuit that is radiation
immune. Operating at a nominal fixed frequency of
525 kHz, these regulated, isolated units utilize well
controlled undervoltage lockout circuitry to eliminate slow
start-up problems. The current sharing function allows a
maximum of five units to be connected in parallel to boost
the total output power to 5 times.
The SVFL series is specifically designed for the harsh
radiation environment of space applications. Performance
is guaranteed through the use of hardened semiconductor
components, radiation lot acceptance testing (RLAT) of
non-hardened components and analysis. The SVFL series
has been characterized for Total Ionizing Dose (TID)
performance including Enhanced Low Dose Rate
Sensitivity (ELDRS) and for Single Event Effects (SEE)
according to VPT’s DLA approved Radiation Hardness
Assurance (RHA) plan per MIL-PRF-38534, Appendix G.
Characterization is performed at both the component level
and at the SVFL series hybrid converter level.
These converters are designed and manufactured in a
facility qualified to ISO9001 and certified to MIL-PRF-
38534 Class H and Class K and MIL-STD-883.
This product may incorporate one or more of the following
U.S. patents:
5,784,266
6,005,780
5,790,389
6,084,792
5,963,438
6,118,673
5,999,433
FEATURES
•
Guaranteed TID Performance to 30 krad(Si)
including ELDRS, per VPT’s RHA plan specified per
MIL-PRF-38534, Appendix G, Level P with 2X
margin.
Characterized to 44 MeV-cm
2
/mg with minor
transients only; no dropouts, shutdowns, latch up or
burn out.
High Reliability
Parallel Up to 5 Units With Current Sharing
Output Voltage Trim Up +10% or Down –20%
Wide Input Voltage Range: 16 to 40 Volts per MIL-
STD-704
Up to 120 Watts Output Power
Radiation Immune Magnetic Feedback Circuit
NO Use of Optoisolators
Undervoltage Lockout
Current Limit and Short Circuit Protection
High Input Transient Voltage: 50 Volts for 1 sec per
MIL-STD-704A
Precision Seam Welded Hermetic Package
High Power Density: > 80 W/in
3
Custom Modified Versions May Be Available
Additional Environmental Screening Available
Meets MIL-STD-461 Revisions C, D, E and F EMC
Requirements When Used With VPT’s EMI Filters
MIL-PRF-38534 Element Evaluated Components
Utilized
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Figure 1
– SVFL2800S DC-DC Converter (Exact marking may differ from that shown)
