517345774 Product Details
PCB Mounted Jacks Single Port, Multiport and Stacked
Always EU RoHS/ELV Compliant
(
Statement of Compliance
)
Product Highlights:
Connector
Preloaded
Single Port Configuration
1 x 1 Jack Configuration
Jack Type = RJ45
View all Features
Share
Print
Email
Quick Links
Pricing & Availability
Search for Tooling
Product Feature Selector
Contact Us About This Product
517345774
TE Internal Number: 517345774
Active
Add to My Part List
Request Sample
Find Similar Products
Buy Product
View 3D PDF
Documentation & Additional Information
Product Drawings:
MODULAR JACK, RJ45, 8P8C, DIP TYPE. (PDF, English)
Catalog Pages/Data Sheets:
None Available
Product Specifications:
None Available
Application Specifications:
None Available
Instruction Sheets:
None Available
CAD Files: (CAD Format & Compression Information)
2D Drawing (DXF, Version C)
3D Model (IGES, Version C)
3D Model (STEP, Version C)
Additional Information:
Product Line Information
Related Products:
Tooling
List all Documents
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
Product Type = Connector
Jack Type = RJ45
PCB Mounting Orientation = Top Entry (Vertical)
PCB Mount Style = Through Hole
Performance Category = Cat 3
LED = With
Grounding Options = PCB Ground
Panel Stops = Without
Keyed = No
Profile = Standard
Color = Black
Mechanical Attachment:
Panel Mount Retention = Without
Flanged = No
Termination Features:
Termination Method to PC Board = Solder
Dimensions:
Height (mm [in]) = 16.50 [0.650]
PCB Tail Length (mm [in]) = 3.25 [0.1281]
PCB Thickness, Recommended (mm [in]) = 1.57 [0.062]
Body Features:
Inverted Jack Face = No
Shield Plating = Nickel
Housing Features:
Housing Material = High Temperature Thermoplastic
Configuration Features:
Preloaded = Yes
Port Configuration = Single
Jack Configuration = 1 x 1
Number of Positions = 8
Shielded = Yes
Number of Contacts Loaded = 8
Number of PCB Ground Tabs = 2
Industry Standards:
RoHS/ELV Compliance = RoHS compliant, ELV compliant
Lead Free Solder Processes = Wave solder capable to 240°C, Wave
solder capable to 260°C, Wave solder capable to 265°C
RoHS/ELV Compliance History = Always was RoHS compliant
UL Flammability Rating = UL 94V0
Identification Marking:
LED Position 1 Color = Red, Yellow
LED Position 2 Color = Green/Red
LED Position 3 Color = None
Packaging Features:
Packaging Method = Tray
Packaging Quantity = 100/Tray
Shield Material = Brass
LED Lightpipe Material = Epoxy Resin
PCB Ground Tab Location (mm [in]) = 3.85 [0.152]
Contact Features:
Solder Tail Contact Plating = Gold Flash over Nickel
Contact Plating, Mating Area, Material = Gold (50)
Contact Base Material = Phosphor Bronze
Product Availability:
Region = Asia, North America
Other:
Brand = AMP
