DATA SHEET
MOS INTEGRATED CIRCUIT
µ
PD17015
4-BIT SINGLE-CHIP MICROCONTROLLER FOR PORTABLE RADIOS
The
µ
PD17015 is a super low-voltage 4-bit single-chip microcontroller for digital tuning applications. It features
a prescaler that can operate at frequencies up to 220 MHz, a PLL synthesizer, and an LCD controller/driver, all
configured in one chip.
Since, for its CPU, the
µ
PD17015 adopts a 17K architecture which allows data memory to be manipulated directly
without accumulators, programming efficiency is enhanced. Each instruction is 16 bits (one word) long.
Since this microcontroller can operate at low voltages (V
DD
= 1.8 to 3.6 V), it is ideal for controlling portable, battery-
powered units such as portable radios, headphone stereo sets, and radio-cassette players.
FEATURES
•
•
•
•
•
17K architecture
Program memory (ROM)
Data memory (RAM)
General-purpose I/O ports
• LCD controller/driver
• Clock generator port
: General registers
: 3K bytes (1528
×
16 bits)
: 97
×
4 bits
: 12
: 9 segments
×
4 commons
Minimum required peripheral hardware is built into the chip.
• PLL frequency synthesizer and 220-MHz (MAX.) prescaler
•
Low-voltage operation
ORDERING INFORMATION
Part number
: V
DD
= 1.8 to 3.6 V (T
A
= –10 to +50
°C)
Package
38-pin plastic shrink SOP (300 mil)
µ
PD17015GS-×××-GJG
Remark
×××
is a ROM code number.
The information in this document is subject to change without notice.
Document No. U10416EJ1V0DS00
(1st edition)
Date Published September 1995 P
Printed in Japan
Major changes in this revision are indicated by stars (5) in the margins.
©
