PS7122A-2B-A: DescriptionDUAL TRANSISTOR OUTPUT SOLID STATE RELAY, 1500V ISOLATION-MAX, LEAD FREE, DIP-8; CategoryLED optoelectronic/LED photoelectric; File Size265KB，16 Pages; ManufacturerRenesas Electronics Corporation; Websitehttps://www.renesas.com/; Environmental Compliance

Download Datasheet Parametric Compare View All

PS7122A-2B-A Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	PS7122A-2B-A	-	-	View	Buy Now

PS7122A-2B-A Overview

DUAL TRANSISTOR OUTPUT SOLID STATE RELAY, 1500V ISOLATION-MAX, LEAD FREE, DIP-8

PS7122A-2B-A Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Maker	Renesas Electronics Corporation
Reach Compliance Code	unknow
Other features	UL APPROVED
Configuration	SEPARATE, 2 ELEMENTS
Maximum forward current	0.05 A
Maximum insulation voltage	1500 V
JESD-609 code	e6
Number of components	2
Maximum on-state current	0.2 A
Maximum on-state resistance	8 Ω
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Optoelectronic device types	TRANSISTOR OUTPUT SSR
Terminal surface	Tin/Bismuth (Sn/Bi)
Base Number Matches	1
