5111873-9 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > The connector> The connector> 5111873-9

5111873-9: DescriptionCONNECTOR, 40 CONTACT(S), FEMALE, TWO PART BOARD CONNECTOR, IDC, RECEPTACLE, ROHS COMPLIANT; CategoryThe connector The connector; File Size111KB，1 Pages; ManufacturerTE Connectivity; Websitehttp://www.te.com; Environmental Compliance

Download Datasheet Parametric View All

5111873-9 Overview

CONNECTOR, 40 CONTACT(S), FEMALE, TWO PART BOARD CONNECTOR, IDC, RECEPTACLE, ROHS COMPLIANT

5111873-9 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
package instruction	ROHS COMPLIANT
Reach Compliance Code	unknown
Is Samacsys	N
Body/casing type	RECEPTACLE
Connector type	BOARD CONNECTOR
Contact to complete cooperation	NOT SPECIFIED
Contact completed and terminated	TIN
Contact point gender	FEMALE
Contact material	PHOSPHOR BRONZE
DIN compliance	NO
Filter function	NO
IEC compliance	NO
JESD-609 code	e3
MIL compliance	NO
Manufacturer's serial number	5111873
Mixed contacts	NO
Installation type	CABLE
Options	GENERAL PURPOSE
Termination type	IDC
Total number of contacts	40
UL Flammability Code	94V-0
Base Number Matches	1

Preview

Download Datasheet

View All

My Account

Tyco Electronics

(C hange)

Se arch by Ke yword or Part #

Products

Documentation

Resources

My Account

Customer Support

Home

Products

By Type

Ribbon and Flat Flex Wire C onnectors - Ribbon C able

Product Feature Selector

> Product Details

5111873-9 Product Details

Live Product Chat

Ribbon Cable Connectors (AMP-LATCH)

Always EU R oHS/ELV C om pliant

(

Sta te m e nt of C om pliance

)

Quick Links

C heck Pricing & Availability

Search for Tooling

Product Feature Selector

C ontact Us About This Product

5111873-9

T E I nternal N umber: 5 1 1 1 8 7 3 - 9

Product Highlights:

C onnector Type = NOVO

40 Positions

Receptacle

Mating Polarization Type = C enter & Military

With Mating Polarization

View all Features

Obsolete

C ontact Product Information C enter

View 3D PDF

A dd to M y P art L is t

Reques t Sample

Find Similar P roduc ts

Buy P roduc t

Documentation & Additional Information

Product Drawings:

None Available

Catalog Pages/Data Sheets:

None Available

Product Specifications:

C onnector, Flat C able Round C onductor, AMP-LATC H Nov...

(PDF, English)

Application Specifications:

AMP-LATC H Novo Receptacles for Ribbon C able with C on...

(PDF, English)

Instruction Sheets:

C onnector-Specific Kit f/AMP-LATC H Standard and Novo...

(PDF, English)

CAD Files:

AD Format & C ompression Information)

2D Drawing

(DXF, Version O)

3D Model

(IGES, Version O)

3D Model

(STEP, Version O)

List all Documents

Product Features

(Please use the Product Drawing for all design activity)

Product Type Features:

C onnector Type

= NOVO

Number of Positions

= 40

Gender = Receptacle

Mating Polarization Type = C enter & Military

Mating Polarization

= With

Mounting Ears

= Without

PC B Retention Feature = No

Mating C onnector Lock = Without

Strain Relief = Without

With C over Preassembled = Yes

Termination Related Features:

Solder Tail C ontact Plating

= Tin

Body Related Features:

C enterline, Matrix (mm [in]) = 2.54 x 2.54 [.100 x .100]

Contact Related Features:

C ontact Plating, Mating Area, Material

= Gold (15)

C ontact Base Material = Phosphor Bronze

Housing Related Features:

Housing C olor

= Black

Housing Material = Polyester

Housing Flammability Rating = UL 94V-0

Configuration Related Features:

C able Stop = Without

Industry Standards:

RoHS/ELV C ompliance

= RoHS compliant, ELV compliant

Lead Free Solder Processes

= Not relevant for lead free process

RoHS/ELV C ompliance History = Always was RoHS compliant

Conditions for Usage:

Terminate To

= Ribbon C able

Other:

Brand = AMP

Additional Information:

Product Line Information
