Model 3028 Accelerometer
Piezoresistive MEMS
DC Response, mV Output
Low Cost
Screw Mounted Flange
The Model 3028
is a silicon MEMS
accelerometer in a Wheatstone bridge
configuration. It is packaged on a ceramic
substrate with a metal bracket which can
be used to bolt the sensor to the mounting
location. The accelerometer is offered in
ranges from ±2g to ±200g range and
provides a flat frequency response to
minimum 2000Hz. The silicon MEMS
sensor is gas damped and incorporates
over-range stops for high-g shock
protection.
For a similar accelerometer designed for
adhesive mounting, see the model 3022.
dimensions
FEATURES
•
•
•
•
•
•
•
Bolt Mounted
±0.5% Non-linearity
Open Wheatstone Bridge
DC Response
Gas Damping
Built-in Overrange Stops
Low Power Consumption
APPLICATIONS
•
•
•
•
•
•
Vibration & Shock Monitoring
Motion Control
Impact & Shock Testing
Modal Analysis
Embedded Applications
Machinery
Model 3028 Rev 3
32 Journey Ste. 150 Aliso Viejo, CA 92656
www.meas-spec.com
949-716-5377
10/272009
t&m@meas-spec.com
Model 3028 Accelerometer
performance specifications
All values are typical at +24°C, 100Hz and 5Vdc excitation unless otherwise stated. Measurement Specialties reserves the right to update and change
these specifications without notice. Standard product parameters are described in PSC-1002 for Embedded DC Accelerometers.
Parameters
DYNAMIC
Range (g)
Sensitivity (mV/g)
1
Frequency Response (Hz)
Natural Frequency (Hz)
Non-Linearity (%FSO)
Transverse Sensitivity (%)
Damping Ratio
Shock Limit (g)
ELECTRICAL
Zero Acceleration Output (mV)
Excitation Voltage (Vdc)
Input Resistance (Ω)
Output Resistance (Ω)
Insulation Resistance (MΩ)
Residual Noise (µV RMS)
Ground Isolation
ENVIRONMENTAL
Thermal Zero Shift (%FSO/°C)
Thermal Sensitivity Shift (%/°C)
Operating Temperature (°C)
Compensated Temperature (°C)
Storage Temperature (°C)
Notes
±2
8.0-20.0
0-150
700
±0.5
<3
0.7
5000
±5
6.0-15.0
0-250
800
±0.5
<3
0.7
5000
±10
3.0-6.0
0-400
1000
±0.5
<3
0.7
5000
±20
1.5-3.0
0-600
1500
±0.5
<3
0.7
5000
±25
2 to 10
2500-
6500
2500-
6500
>100
10
±50
0.6-1.5
0-1000
4000
±0.5
<3
0.7
10000
±25
2 to 10
2500-
6500
2500-
6500
>100
10
±100
0.3-0.6
0-1500
6000
±0.5
<3
0.7
10000
±25
2 to 10
2500-
6500
2500-
6500
>100
10
±200
0.15-0.3
0-2000
8000
±0.5
<3
0.6
10000
±25
2 to 10
2500-
6500
2500-
6500
>100
10
@5Vdc Excitation
±5%
<1 Typical
±25
±25
±25
2 to 10
2 to 10
2 to 10
2500-
2500-
2500-
6500
6500
6500
2500-
2500-
2500-
6500
6500
6500
>100
>100
>100
10
10
10
Isolated from Mounting Surface
-0.09
-0.09
-0.15
-0.15
-40 to +125
Uncompensated
-40 to +125
-0.09
-0.15
Differential
@50Vdc
Maximum
-0.09
-0.15
-0.09
-0.15
-0.09
-0.15
-0.09
-0.15
Typical
Typical
PHYSICAL
Case Material
Aluminum Flange, Ceramic Cover
Cable
Not applicable
Weight (grams)
4.5
Mounting
2x #4-40 Mounting Screws
Mounting Torque
6 lb-in (0.7 N-m)
AWG
Not applicable
1
Output is ratiometric to excitation voltage
2
The maximum recommended soldering temperature is +260°C
Wiring color code:
See schematic
The information in this sheet has been carefully reviewed and is believed to be accurate; however, no responsibility is assumed for inaccuracies. Furthermore, this
information does not convey to the purchaser of such devices any license under the patent rights to the manufacturer. Measurement Specialties, Inc. reserves the right
to make changes without further notice to any product herein. Measurement Specialties, Inc. makes no warranty, representation or guarantee regarding the suitability of
its product for any particular purpose, nor does Measurement Specialties, Inc. assume any liability arising out of the application or use of any product or circuit and
specifically disclaims any and all liability, including without limitation consequential or incidental damages. Typical parameters can and do vary in different applications.
All operating parameters must be validated for each customer application by customer’s technical experts. Measurement Specialties, Inc. does not convey any license
under its patent rights nor the rights of others.
ordering info
PART NUMBERING
Model Number+Range+Electrical Connection
3028-GGG-P
l l
l l_____Electrical Connection (P=pins, N=solder pads)
l___________Range (010 is 10g)
Example: 3028-010-P
Model 3028, 10g, Pins
